Запчасти Doosan Daewoo CYLINDER BLOCK ENGINE PARTS

152
178
179
180
181
153
102
155
154
331
119
155
332
122
150
123
126
119
151
148
122
117
123
149
120
121
144
140
145
117
146
118
147
117
132
131
121
120
121
109
120
160
107
158
159
105
108
156
132
127
131
116
114
112
110
135
162
111
161
142
141
113
201
182
202
175
176
152
177
137
117
163
174
173
131
132
139
138
125
128
124
115
125
132
124
131
136
136

Артикул

Название

Примечание

Количество

102

65.01101-6819C

CYLINDER BLOCK ASS'Y

desc: BLOC CYLINDRES

1шт.

105

65.01101-6806C

CYLINDER BLOCK

SC: D

1шт.

107

65.01105-6014

BEARING CAP ASS'Y(TH)

SC: D

1шт.

108

65.01105-1162

CAP;BEARING

SC: D

1шт.

109

65.91301-0071

PIN

desc: .. TIGE

2шт.

110

65.01105-6013

BEARING CAP ASS'Y

SC: D

4шт.

111

06.22022-3061

PIN;DOWEL 8H8X18

desc: .. TIGE

2шт.

112

65.01105-1162

CAP;BEARING

SC: D

1шт.

113

65.90020-0293A

BOLT;BEARING CAP(MAIN)

desc: . BOULON A 6 PANS

10шт.

114

06.01494-4316

BOLT;HEX. M12X1.5X85

desc: . BOULON A 6 PANS

10шт.

115

65.04410-0018

BUSH;CAMSHAFT

desc: . COUSSINET

1шт.

116

65.04410-0078

BUSH;CAMSHAFT

desc: . COUSSINET

4шт.

117

65.91606-0039

PLUG;CORE

desc: . BOUCHON B28D

10шт.

118

65.91606-0037

PLUG;CORE HOLE

desc: . BOUCHON B28D

2шт.

119

06.15090-2319

PLUG;CORE

desc: . BOUCHON B28D

2шт.

120

65.90310-0149A

SCREW;PLUG M26X1.5

desc: . BOUCHON A VIS

6шт.

121

06.56190-0726

RING;SEAL

desc: . BAGUE D'ETANCHEITE

6шт.

122

65.90310-0132

SCREW;PLUG

desc: . BOUCHON A VIS

2шт.

123

06.56190-0718

RING;SEAL

desc: . BAGUE

2шт.

124

65.90310-0134

SCREW;PLUG

desc: . VIS

2шт.

125

06.56190-0732

RING;SEAL

desc: . CONTACT DE NIVEAU D'HUILE

2шт.

126

06.31641-0615

BALL;STEEL

desc: . BILLE

1шт.

127

06.22022-1063

PIN;DOWEL

desc: . GOUJON D'ASSEMBLAGE

2шт.

128

06.22022-3563

PIN;DOWEL

desc: . GOUJON D'ASSEMBLAGE

2шт.

131

65.90310-0135

SCREW;PLUG

desc: BOUCHON A VIS

4шт.

132

06.56190-0706

RING;SEAL

desc: BAGUE D'ETANCHEITE

4шт.

135

65.91605-0013

COVER

desc: COUVERCLE

1шт.

136

65.01110-6522A

METAL;MAIN

SERIAL: 010110

4шт.

136

65.01110-6522B

METAL;MAIN

SERIAL: 010111

4шт.

136

65.01110-6523

METAL;MAIN (0.10)

SC: OS

4шт.

136

65.01110-6524

METAL;MAIN (0.25)

SC: OS

4шт.

137

65.01111-6539

METAL;THRUST

desc: PALIER

1шт.

137

65.01111-6523

METAL;MAIN (0.10)

SC: OS

1шт.

137

65.01111-6524

METAL;MAIN (0.25)

SC: OS

1шт.

138

65.90310-0131

SCREW;PLUG

desc: VIS

1шт.

139

06.56190-0713

RING;SEAL

desc: BAGUE D'ETANCHEITE

1шт.

140

65.91701-0274

PIN;LOCATING

desc: BROCHE

16шт.

141

65.90310-0134

SCREW;PLUG

desc: VIS

2шт.

142

06.56190-0732

SEAL;RING

desc: CONTACT DE NIVEAU D'HUILE

2шт.

144

65.01201-0049A

LINER;CYLINDER

desc: CHEMISE DE CYLINDRE

8шт.

145

65.96501-0059

O-RING;CYLINDER LINER UPPER

desc: JOINT TORIQUE

16шт.

146

51.96501-0412

O-RING

desc: JOINT TORIQUE

8шт.

147

65.96501-0078

O-RING (LOW)

desc: JOINT TORIQUE

8шт.

148

65.98130-0066

ADAPTER;OIL PRESS

desc: RACCORD ADAPTATEUR

1шт.

149

06.56190-0728

RING;SEAL

desc: BAGUE D'ETANCHEITE

1шт.

150

65.27441-7007

SWITCH;OIL PRESS

desc: MANOCONTACT DE PRESSION D'HUILE

1шт.

151

65.98131-0060

SCREW;CONNECTION

desc: VIS

1шт.

152

06.56190-0706

RING;SEAL

desc: BAGUE D'ETANCHEITE

1шт.

153

65.06301-5117A

C/W PIPE ASS'Y

desc: CONDUITE

1шт.

154

04.27405-0220

HOSE;RUBBER

desc: TUYAU FLEXIBLE

1шт.

155

65.97440-0045

CLAMP;HOSE

desc: COLLIER

2шт.

156

65.06312-0008

FLANGE (BLOCK-S.TANK)

desc: RACCORD

1шт.

158

06.56250-2006

GASKET(C/W PIPE FLANGE)

desc: JOINT

1шт.

159

06.01013-9213

BOLT;HEX. M10X40

desc: BOULON A 6 PANS

2шт.

160

06.16731-2108

WASHER;SPRING

desc: RONDELLE

2шт.

161

65.90310-0140

SCREW;PLUG M16x1.5

desc: BOUCHON

2шт.

162

06.56190-0708

RING;SEAL

desc: BAGUE D'ETANCHEITE A16X20

2шт.

163

65.01601-5063

OIL SPRAY NOZZLE ASS'Y

desc: ENSEMBLE REFROIDISSEUR D'HUILE

8шт.

173

65.90001-0129

BOLT;HEX. M6X28

desc: BOULON A 6 PANS

16шт.

174

06.16044-0208

WASHER;SPRING

desc: RONDELLE PLATE

16шт.

175

65.01601-2016A

FLANGE ASS'Y

desc: BRIDE

8шт.

176

65.96601A0237

GASKET

desc: JOINT

8шт.

177

65.98150-0051

SCREW;HOLLOW

desc: VIS CREUSE

8шт.

178

65.19202-0009D

HOOK;LIFTING

desc: SUPPORT

1шт.

179

06.01283-7719

BOLT;HEX. M20X40

desc: BOULON A 6 PANS

1шт.

180

06.16731-2113

WASHER;SPRING

desc: RONDELLE ELASTIQUE

1шт.

181

06.01914-3215

BOLT ASS'Y M10X25

desc: BOULON A 6 PANS

1шт.

182

65.01803-0007

PLATE;BAFFLE

desc: PLAQUE

1шт.

201

65.41530-0148

BRACKET;ENGINE MOUNTING(FR)

desc: SUPPORT

2шт.

202

06.01914-3320

BOLT ASS'Y M12X45

desc: BOULON A 6 PANS

8шт.

331

65.05701-0141A

PIPE;OIL SEPARATOR

desc: CONDUITE

1шт.

332

06.56190-0739

RING;SEAL

desc: CONTACT DE NIVEAU D'HUILE

1шт.

Выбрано товаров: 72
