Запчасти Doosan Daewoo CRANK SHAFT ENGINE PARTS

101

65.02101-7397A

CRANK SHAFT ASS'Y

desc: VILEBREQUIN

1шт.

102

65.02101-0048A

SHAFT;CRANK

SC: D

1шт.

104

65.02110-0101A

WEIGHT;BALANCE

desc: . MASSE D'EQUILIBRAGE

4шт.

106

65.02110-0104A

WEIGHT;BALANCE

desc: . MASSE D'EQUILIBRAGE

2шт.

108

65.90030-0048A

BOLT;BALANCE WEIGHT

desc: . BOULON A 6 PANS

12шт.

109

65.02130-0001

RING;WEAR(FRONT)

desc: SEGMENT D'USURE

1шт.

111

65.02115-0066

GEAR;CRANK SHAFT

desc: PIGNON DE VILEBREQUIN

1шт.

113

06.22022-3065

PIN;PARALLEL

desc: BROCHE

1шт.

114

65.01505-0007

RING;OIL THROWER

desc: BAGUE DE SOUTIEN

1шт.

201

65.02201-7022A

DAMPER;VIBRATION

desc: VOLANT

1шт.

202

65.90020-0062B

BOLT;HEX. M10X20

desc: BOULON A 6 PANS

8шт.

203

06.15010-2312

WASHER;PLAIN 10.5

desc: RONDELLE

8шт.

301

65.02301-5101

FLY WHEEL ASS'Y

desc: CARTER DE VOLANT MOTEUR

1шт.

302

65.02301-0247

FLYWHEEL

SC: D

1шт.

303

65.02310-0073C

GEAR;RING

SC: D

1шт.

304

65.91303-0005

PIN;TAPER

desc: BROCHE

1шт.

305

65.90020-0127

BOLT;FLY WHEEL

desc: BOULON A 6 PANS

10шт.

306

65.02130-0002

RING;WEAR(REAR)

desc: SEGMENT D'USURE

1шт.

401

06.02101-0817

BOLT;SOCKET HEAD M16X1.5

desc: VIS A 6 PANS CREUX

8шт.

402

65.02601-0175

PULLEY;V-BELT

desc: POULIE

1шт.
