Запчасти Doosan Daewoo COOLING SYSTEM ENGINE PARTS

101

65.06630-5012

FAN DAMPER ASS'Y

desc: FIXATION DE POMPE

1шт.

104

06.01913-3115

BOLT ASS'Y M8X25

desc: BOULON A 6 PANS

6шт.

105

65.06601-0016A

FAN;COOLING

desc: VENTILATEUR

1шт.

106

06.01913-3212

BOLT ASS'Y M10X18

desc: BOULON A 6 PANS

6шт.

107

65.06611-0101A

FLANGE;FAN

desc: BRIDE

1шт.

108

06.01913-3117

BOLT ASS'Y M8X30

desc: BOULON A 6 PANS

6шт.

109

65.06640-0017

BRACKET;FAN GUIDE(L.H.)

desc: SUPPORT

1шт.

110

65.06640-0019

BRACKET;FAN GUIDE(R.H.)

desc: SUPPORT

1шт.

111

06.11063-8215

NUT;HEX. M10

desc: ECROU 6 PANS

4шт.

112

06.16731-2108

WASHER;SPRING

desc: RONDELLE

4шт.

113

65.06640-0020

BRACKET;FAN GUIDE(MID)

desc: SUPPORT

1шт.

114

06.01283-7214

BOLT;HEX. M10X22

desc: VIS 6 PANS

2шт.

115

06.16731-2108

WASHER;SPRING

desc: RONDELLE

2шт.

201

65.06660-5002A

FAN GUIDE ASS'Y

desc: VENTILATEUR

1шт.

216

65.06662-6001

RUBBER CUSHION ASS'Y

desc: CAOUTCHOUC

3шт.

217

65.06662-5001

CUSHION;RUBBER

SC: D

2шт.

218

65.91701-0150

TUBE

SC: D

1шт.

219

06.01283-3221

BOLT;HEX

SC: D

1шт.

220

06.15010-4312

WASHER;SPRING

SC: D

1шт.

221

06.16731-6108

WASHER;PLAIN

SC: D

1шт.

222

06.11063-8215

NUT;HEX

SC: D

1шт.

301

65.06630-5012

FAN DAMPER ASS'Y

desc: FIXATION DE POMPE

1шт.

304

06.01913-3115

BOLT ASS'Y M8X25

desc: BOULON A 6 PANS

6шт.

305

65.06601-5062

FAN;COOLING

desc: VENTILATEUR

1шт.

306

06.01913-3212

BOLT ASS'Y M10X18

desc: BOULON A 6 PANS

6шт.

307

65.06611-0124

FLANGE;FAN

desc: BRIDE

1шт.

308

06.01913-3121

BOLT ASS'Y M8X50

desc: BOULON A 6 PANS

6шт.
