Запчасти Doosan Daewoo CAM SHAFT ENGINE PARTS

101

65.04101-0375B

VALVE;INTAKE

desc: SOUPAPE D'ADMISSION

8шт.

102

65.04101-0367B

VALVE;EXHAUST

desc: VANNE

8шт.

103

65.90701-0103

WASHER;INNER

desc: RONDELLE

16шт.

104

65.90701-0104

WASHER;OUTER

desc: RONDELLE

16шт.

105

65.04102-6007

VALVE SPRING ASS'Y

desc: VANNE RESSORT

16шт.

106

65.04102-0083A

SPRING;VALVE(OUTER)

desc: . RESSORT

1шт.

107

65.04102-0084A

SPRING;VALVE(INNER)

desc: . RESSORT

1шт.

108

65.04103-0074

RETAINER;VALVE SPRING

desc: SIEGE DE RESSORT DE SOUPAPE

16шт.

109

51.04104-0023

VALVE;COTTER

desc: CLAVETTE DE SOUPAPE

32шт.

110

65.04902-0027

SEAL;VALVE STEM

desc: JOINT DE QUEUE DE SOUPAPE

16шт.

201

65.04200-6026A

ROCKER ARM ASS'Y

desc: AXE DE CULBUTEUR

8шт.

202

65.04201-6078

ROCKER ARM ASS'Y

desc: . ENSEMBLE AXE DE CULBUTEURS

2шт.

203

65.04201-1003

ARM;ROCKER

SC: D

1шт.

205

65.93020-1011

BUSH;ROCKER ARM

SC: D

1шт.

206

65.04205-0021

SCREW;ADJUST

desc: . VIS

2шт.

207

65.90501-0049

NUT;HEX

desc: . ECROU 6 PANS

2шт.

208

65.04202-5035

RETAINER BRACKET ASS'Y

desc: . BAGUE

1шт.

209

65.90701-0136B

RETAINER WASHER ASS'Y

desc: . BAGUE

2шт.

210

06.29010-0120

RING;SNAP

desc: . CIRCLIP

2шт.

211

65.90001-0146

BOLT;HEX

desc: BOULON A 6 PANS

16шт.

302

65.04301-0079

TAPPET;VALVE

desc: POUSSOIR DE TIGE DE CULBUTEUR

16шт.

303

65.04302-0026

ROD;PUSH

desc: TIGE DE POUSSOIR

16шт.

402

65.04401-6190

CAM SHAFT ASS'Y

desc: CAME ARBRE

1шт.

404

65.04401-0487

SHAFT;CAM

SC: D

1шт.

407

65.11105-6030

TIMER ASS'Y

SC: D

1шт.

408

65.04501-6014

CAMSHAFT GEAR ASS'Y

SC: D

1шт.

414

65.11301-6007

DRIVE GEAR ASS'Y

SC: D

1шт.

419

65.11136-0008

WEIGHT

SC: D

2шт.

420

65.04407-0009

RING;STOP

SC: D

1шт.

421

65.97601-0206

SPRING;COMP

SC: D

2шт.
