Запчасти Doosan Daewoo TURBO CHARGER ENGINE PARTS

101

65.09100-7087

TURBO CHARGER

desc: TURBO CHARGER

1шт.

102

65.09100-7088

TURBO CHARGER

desc: TURBO CHARGER

1шт.

103

65.90201-0072

BOLT;STUD M10X1.5X30

desc: BOUCHON

12шт.

104

65.90201-0073

BOLT;STUD

desc: BOUCHON

8шт.

105

06.11024-9202

NUT M10X1.25

desc: ECROU

8шт.

106

65.09901-0012

GASKET

desc: JOINT

2шт.

107

06.11063-8215

NUT;HEX. M10

desc: ECROU 6 PANS

12шт.

108

06.16030-8208

WASHER;DOUBLE TAB

desc: RONDELLE

20шт.

109

65.09901-0018A

GASKET

desc: JOINT

2шт.

110

65.08202-0111

STAKE;INTAKE

desc: COLLECTEUR

1шт.

111

65.08240-0012

BRACKET;INTAKE STAKE

desc: SUPPORT

1шт.

112

06.01923-3215

BOLT ASS'Y M10X25

desc: BOULON A 6 PANS

4шт.

117

65.96301-0274

HOSE

desc: TUYAU FLEXIBLE

2шт.

118

06.67020-0112

CLAMP;HOSE

desc: COLLIER A DURITE NWS5748

4шт.

121

65.96903-0010

CAP;RUBBER(AIR IN)

desc: CHAPEAU

1шт.

122

65.05701-6077

OIL PIPE ASS'Y(R.H.)

desc: TUYAU

1шт.

123

65.97401-0110A

PIPE;CLIP

desc: ATTACHE DE TUYAU

1шт.

124

65.91701-0086

SPACER

desc: BAGUE D'ECARTEMENT

1шт.

125

06.01923-3124

BOLT ASS'Y M8X65

desc: BOULON A 6 PANS

1шт.

126

65.05701-6063

OIL D/PIPE ASS'Y(L.H.)

desc: TUYAU

1шт.

127

65.05715-0031C

FLANGE;OIL RETURN

desc: BRIDE

2шт.

128

65.96601-0046A

GASKET

desc: JOINT

2шт.

129

06.01923-3119

BOLT ASS'Y M8X40

desc: BOULON A 6 PANS

4шт.

130

65.98131-0070

NIPPLE

desc: GRAISSEUR

2шт.

131

06.56190-0706

RING;SEAL

desc: BAGUE D'ETANCHEITE

2шт.

132

65.90710-0250A

SPACER

desc: RONDELLE PLATE

1шт.

133

06.56190-0706

RING;SEAL

desc: BAGUE D'ETANCHEITE

3шт.

134

65.98103-0024

UNION;BANJO

desc: RACCORD

1шт.

135

65.98150-0044A

SCREW;HOLLOW

desc: VIS CREUSE

1шт.

136

65.05701-5207

PIPE;T/C O/RTRN(R.H.)

desc: CONDUITE

1шт.

137

65.05701-5206

PIPE;T/C O/RTRN(L.H.)

desc: CONDUITE

1шт.

138

65.05701-5175

PIPE;OIL RETURN

desc: CONDUITE

1шт.

139

65.98130-0068

NIPPLE

desc: GRAISSEUR

1шт.

140

06.56190-0728

RING;SEAL

desc: BAGUE D'ETANCHEITE

1шт.

141

65.96301-0327

HOSE;RUBBER

desc: TUYAU FLEXIBLE

2шт.

142

65.08150-0001

LAGGING

desc: LAGGING

2шт.

143

06.67020-0106

CLAMP;HOSE

desc: COLLIER

4шт.

144

65.96601A0030

GASKET;T/C OIL RETURN

desc: JOINT

2шт.

145

06.01913-3114

BOLT ASS'Y M8X22

desc: BOULON A 6 PANS

4шт.
