Запчасти Doosan Daewoo OIL COOLER ENGINE PARTS

101

65.05501-7010

OIL FILTER ASS'Y

desc: FILTRE DE HUILE

1шт.

102

65.05503-5049

HEAD;OIL FILTER

desc: . COUVERCLE

1шт.

103

06.31641-0433

BALL;STEEL

desc: . BALLIER

1шт.

104

65.97601-0075

SPRING

desc: . RESSORT

1шт.

105

65.90310-0065

SCREW;PLUG

desc: . VIS

1шт.

106

06.56190-0728

RING;SEAL A26X32

desc: . BAGUE D'ETANCHEITE

1шт.

107

65.05510-5023

CARTRIDGE;OIL FILTER

desc: . ELEMENT FILTRE

1шт.

108

65.05901-0025

GASKET;FILTER-COVER

desc: JOINT

1шт.

109

06.01913-3229

BOLT;ASS'Y M10x90

desc: BOULON A 6 PANS

3шт.

110

06.01013-9227

BOLT;HEX. M10X120

desc: BOULON A 6 PANS

2шт.

111

06.15010-2312

WASHER;PLAIN

desc: RONDELLE

5шт.

112

06.16731-2108

WASHER;SPRING

desc: RONDELLE

2шт.

201

65.05604-0017

HOUSING;OIL COOLER

desc: CARTER

1шт.

202

65.05604-0012

PLATE

desc: PLAQUE

1шт.

203

06.01923-3111

BOLT ASS'Y M8X16

SERIAL: 011023

2шт.

203

65.90020-0068

BOLT ASS'Y M8X16

SERIAL: 011024

2шт.

204

65.05901-0014

GASKET;OIL COOLER

desc: JOINT

1шт.

205

06.01284-7218

BOLT;HEX. M10X35

desc: BOULON A 6 PANS

6шт.

206

06.01014-9226

BOLT;HEX

desc: BOULON A 6 PANS

1шт.

207

06.16731-2108

WASHER;SPRING

desc: RONDELLE

7шт.

208

65.90020-0063B

BOLT;SOCKET HEAD

desc: BOULON A 6 PANS CREUX

3шт.

210

65.05601-7135

OIL COOLER ASSY

desc: REFROIDISSEMENT DE L'HUILE

1шт.

211

65.05605-0025A

COVER;OIL COOLER HOUSING

desc: COUVERCLE

1шт.

212

65.96601-0221B

GASKET

desc: JOINT

2шт.

213

06.01013-9113

BOLT;HEX M8X40

desc: BOULON A 6 PANS

4шт.

214

06.16044-0210

WASHER;SPRING

desc: RONDELLE ELASTIQUE B8

4шт.

215

65.90310-0135

SCREW;PLUG

desc: BOUCHON A VIS

1шт.

216

06.56190-0706

RING;SEAL

desc: BAGUE D'ETANCHEITE

1шт.

217

06.01923-3113

BOLT ASS'Y M8X20

desc: BOULON A 6 PANS

1шт.

218

65.05902A0038

GASKET;COVER-HOUSING

desc: JOINT

1шт.

219

06.01284-7117

BOLT;HEX. M8X30

desc: BOULON A 6 PANS

12шт.

220

06.01284-7115

BOLT;HEX. M8X1.25X25

desc: BOULON A 6 PANS

1шт.

221

06.16044-0210

WASHER;SPRING

desc: RONDELLE ELASTIQUE B8

13шт.

222

65.90310-0133

SCREW;PLUG

desc: VIS

2шт.

223

06.56190-0726

RING;SEAL

desc: BAGUE D'ETANCHEITE

2шт.

224

65.90310-0134

SCREW;PLUG

desc: VIS

1шт.

225

06.56190-0732

RING;SEAL

desc: CONTACT DE NIVEAU D'HUILE

1шт.
