Запчасти Doosan Daewoo INTAKE MANIFOLD ENGINE PARTS

101

65.08201-5250A

MANIFOLD;INTAKE

desc: COLLECTEUR

2шт.

102

06.01923-3132

BOLT ASS'Y M8X110

desc: BOULON A 6 PANS

8шт.

103

06.01923-3129

BOLT ASS'Y M8X90

desc: BOULON A 6 PANA

8шт.

104

65.08902C0078

GASKET;INTAKE MANIFOLD

desc: JOINT

8шт.

105

65.08202-5039

PIPE;EQUALIZING

desc: TUYAU

1шт.

106

06.01923-3226

BOLT ASS'Y M10X75

desc: BOULON A 6 PANS

4шт.

107

06.01013-9222

BOLT;HEX. M10X1.5X85

desc: BOULON A 6 PANS

2шт.

108

06.15010-2312

WASHER;PLAIN

desc: RONDELLE

2шт.

109

06.16731-2108

WASHER;SPRING

desc: RONDELLE

2шт.

110

65.08902A0057

GASKET

desc: JOINT

3шт.

111

65.08202-0112

FLANGE;INLET(L.H.)

desc: BRIDE

1шт.

112

65.26803-7029

HEATER;AIR

desc: RECHAUFFEUR D'AIR

2шт.

114

65.08202-0113

FLANGE;INLET(R.H.)

desc: BRIDE

1шт.

115

06.01923-3226

BOLT ASS'Y M10X75

desc: BOULON A 6 PANS

6шт.

116

65.08902A0057

GASKET

desc: JOINT

3шт.

117

65.08220-0002A

PIPE;CONNECTION

desc: TUYAU

2шт.

118

65.96501-0058

O-RING

desc: JOINT TORIQUE

4шт.

119

65.19102-5002

BRACKET;ALTERNATOR MOUNTING

desc: SUPPORT

1шт.

120

06.01013-9220

BOLT;HEX. M10X1.5X75

desc: BOULON A 6 PANS

1шт.

121

06.16731-2108

WASHER;SPRING

desc: RONDELLE

1шт.

122

06.11063-8215

NUT;HEX

desc: ECROU 6 PANS

1шт.

123

65.19103-6012

EYE BOLT ASS'Y

desc: BOULON A 6PANS

1шт.

124

06.01943-3318

BOLT ASS'Y M12X1.5X35

desc: BOULON A 6 PANS

1шт.
