Запчасти Doosan Daewoo RADIATOR BODY PARTS

-

201-00001A

ENGINE ASS'Y

SC: D

-2шт.

20

2202-9083A

RADIATOR ASS'Y(FAN 27.5")

SERIAL: 1001-1057

1шт.

20

202-00079

RADIATOR ASS'Y(FAN 30")

SERIAL: 1058

1шт.

20A

13D91000

RADIATOR

desc: . RADIATEUR

1шт.

20B

13D92000

OIL COOLER ASS'Y

desc: . CONDUITES DE HUILE

1шт.

20C

13D93000

FRAME ASS'Y

desc: . BATI PRINCIPAL

1шт.

20D

13D94000

SHROUD ASS'Y

SERIAL: 1001-1057

1шт.

20D

13F34000

SHROUD ASS'Y

SERIAL: 1058

1шт.

20E

13D95000

WIRE NET ASS'Y

desc: . CABLE

2шт.

20F

13D96000

SIDE SUPPORT

desc: . PORTE

4шт.

20G

P06A

CAP ASS'Y

desc: . BOUCHON

1шт.

20H

P04

DRAIN COCK ASS'Y

desc: . ROBINET

1шт.

20I

P03

DRAIN HOSE

desc: . TUYAU FLEXIBLE

1шт.

20J

P1110

BOLT M10X1.25X20

SERIAL: 1001-1057

34шт.

20J

P1110B

BOLT M10X1.25X20

SERIAL: 1058

34шт.

20K

P1111

FLANGE NUT

desc: . ECROU

16шт.

20L

P1106

BOLT

desc: . BOULON A 6 PANS

4шт.

20M

P1306

WASHER;PLAIN

desc: . RONDELLE

4шт.

20N

P1406

WASHER;SPRING

desc: . RONDELLE ELASTIQUE

4шт.

20O

P22

SPONGE

desc: . MOUSSE DE CAOUTCHOUC

4шт.

20P

13D97000

WIRE 210L

desc: . CABLE

2шт.

20R

P1310

WASHER;PLAIN

SERIAL: 1001-1057

8шт.

20R

P1310

WASHER;PLAIN

SERIAL: 1058

11шт.

20S

P1410

WASHER;SPRING

SERIAL: 1058

8шт.

20T

13F38000

GUARD;FAN

SERIAL: 1058

1шт.

20U

-

BOLT M8X1.25X15

SERIAL: 1058

4шт.
