Запчасти Doosan Daewoo OIL COOLER PIPING(1) BODY PARTS

-

2400-2152B

OIL COOLER PIPING

SC: D

-2шт.

1

2140-1697C

PIPE;SUCTION

SERIAL: 1001-1070

1шт.

1

2140-1697E

PIPE;SUCTION

SERIAL: 1071

1шт.

11

2185-1737D6

HOSE 315L

desc: TUYAU FLEXIBLE

1шт.

12

2185-1002D106

HOSE 1000L

desc: TUYAU FLEXIBLE

1шт.

13

2184-1197D60

HOSE 1400L

desc: TUYAU FLEXIBLE

1шт.

14

2184-1212D28

HOSE 800L

desc: TUYAU FLEXIBLE

1шт.

20

2180-1026D32

O-RING

desc: JOINT TORIQUE

1шт.

21

S8030121

O-RING

desc: JOINT TORIQUE

4шт.

22

S8000241

O-RING

desc: JOINT TORIQUE

3шт.

23

S8000231

O-RING

desc: JOINT TORIQUE

2шт.

26

S5110901

WASHER;SPRING M16

SERIAL: 1001-1064

4шт.

26

S5110903

WASHER;SPRING M16

SERIAL: 1065

4шт.

30

S2221461

BOLT;SOCKET M16X2.0X40

SERIAL: 1001-1064

4шт.

30

S2221466

BOLT;SOCKET M16X2.0X40

SERIAL: 1065

4шт.

34

S8450127

CLAMP;HOSE

desc: COLLIER

4шт.

35

S8450035

CLAMP;HOSE

desc: COLLIER

4шт.

37

2181-4133D5

ADAPTER

desc: RACCORD ADAPTATEUR

2шт.

38

2181-2628D1

ELBOW;ORFS

desc: COUDE

2шт.

42

2181-2693A

ADAPTER

desc: ADAPTEUR

1шт.
