Запчасти Doosan Daewoo PROPELLING PIPING TRACK PARTS

-

2400-1689

PIPING;PROPELLING

SERIAL: 1-48

-2шт.

1

2183-4709A

PIPE

desc: TUYAU

2шт.

2

2183-4714

PIPE

desc: TUYAU

2шт.

3

2183-4707

PIPE

desc: TUYAU

1шт.

4

2183-4708

PIPE

desc: TUYAU

1шт.

5

2183-4706A

PIPE

desc: TUYAU

1шт.

6

2184-1205D1

HOSE PF1 1/4-2590L

desc: TUYAU FLEXIBLE

2шт.

7

2184-1205D2

HOSE PF1 1/4-2400L

desc: TUYAU FLEXIBLE

2шт.

8

2184-1036D27

HOSE PF3/8-2300L

desc: TUYAU FLEXIBLE

2шт.

9

2184-1046D184

HOSE PF1/2-2300L

desc: TUYAU FLEXIBLE

2шт.

10

2180-1026D19

O-RING SAE 1 "

desc: JOINT TORIQUE

4шт.

11

S2215361

BOLT;SOCKET M12X1.75X35

desc: BOULON A 6 PANS CREUX

16шт.

12

2180-1026D23

O-RING SAE 1 1/4"

desc: JOINT TORIQUE

8шт.

13

2181-9086

FLANGE;SPLIT 1.25" 6000psi

desc: FLASQUE EN DEUX PARTIES

16шт.

14

S2218461

BOLT;SOCKET M14X2.0X40

desc: BOULON A 6 PANS CREUX

24шт.

14

S2218461

BOLT;SOCKET M14X2.0X40

desc: BOULON A 6 PANS CREUX

12шт.

15

S2218761

BOLT;SOCKET M14X2.0X55

desc: BOULON A 6 PANS CREUX

8шт.

16

S8000141

O-RING P14

REP_PNO: 8202-011

6шт.

17

2181-1126D7

ADAPTER PFO3/8. PF3/8

desc: RACCORD

6шт.

18

S8000241

O-RING P24

desc: JOINT TORIQUE

3шт.

19

2181-1126D1

ADAPTER PFO3/4. PF3/4

desc: RACCORD

1шт.

20

2181-1126D24

ADAPTER PFO3/4. PF1/2

desc: RACCORD

2шт.

21

S8180341

SEAL;RING M22

desc: RONDELLE ETANCHE

2шт.

22

2181-4246

ADAPTER M22X1.5. PF1/2

desc: RACCORD

2шт.

23

S8180211

SEAL;RING M14

desc: RONDELLE

4шт.

24

2181-4245

ADAPTER M14X1.5. PF3/8

desc: RACCORD

2шт.

25

2181-2557

ADAPTER PF1/4. PF3/8

desc: RACCORD

2шт.

26

2195-4608A

BRACKET

desc: SUPPORT

1шт.

27

S0512053

BOLT M10X1.5X25

desc: BOULON A 6 PANS

8шт.

28

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

11шт.

29

2124-4055

CLAMP;PIPE

desc: ATTACHE DE TUYAU

1шт.

30

S0512253

BOLT M10X1.5X30

desc: BOULON A 6 PANS

1шт.

31

2124-4054

CLAMP;PIPE

desc: ATTACHE DE TUYAU

1шт.

32

S0512353

BOLT M10X1.5X35

desc: BOULON A 6 PANS

2шт.

33

2124-1353D12

CLAMP

desc: ATTACHE

4шт.

34

2124-1353D13

CLAMP

desc: ATTACHE

2шт.

35

2160-4023

BUSHING;RUBBER

desc: COUSSINET

4шт.

36

2124-1084D3

CLIP;BAND

desc: ATTACHE

6шт.

37

2184-1036D90

HOSE 3/8.2600

SERIAL: 4

2шт.

38

S2220261

BOLT;SOCKET M14X2.0X130

SERIAL: 4

12шт.
