Запчасти Doosan Daewoo TRACK SHOE ASSY-750G OPTION PARTS

-

2273-6072D1

TRACK SHOE ASS'Y(750mm)

SERIAL: 114

2шт.

1

2272-6186

TRACK LINK ASS'Y

desc: ENSEMBLE MAILLON DE CHAINES

1шт.

1-1

2272-6188

LINK(R.H.)

desc: . PIECE DE JONCTION

53шт.

1-2

2272-6187

LINK(L.H.)

desc: . PIECE DE JONCTION

53шт.

1-3

2110-6079

BUSHING;TRACK LINK

desc: . COUSSINET

52шт.

1-4

2110-6080

BUSHING;MASTER

desc: . DOUILLE PRINCIPALE

1шт.

1-5

2123-6105

PIN;TRACK LINK

desc: . GOUPILLE

52шт.

1-6

2123-6106

PIN;MASTER

desc: . GOUPILLE

1шт.

1-7

2114-6048

SPACER;TRACK LINK

desc: . BAGUE

2шт.

1-8

2180-6091

SEAL;TRACK LINK

desc: . BAGUE

104шт.

2

2273-6073D1

SHOE 750MM.20T

desc: SABOT

53шт.

3

2120-6030

BOLT;TRACK SHOE M22X1.5X75

desc: BOULON A 6 PANS

212шт.

4

2121-6037

NUT;TRACK SHOE M22X1.5

desc: ECROU

212шт.

5

2190-1921D61

PLATE;NAME(SPEC.)

desc: PLAQUE SIGNALETIQUE

1шт.

6

2190-3134D1

PLATE;NAME

desc: PLAQUE SIGNALETIQUE

2шт.
