Запчасти Doosan Daewoo F.O.P.S GUARD ASSY OPTION PARTS

-

2623-1248

FOPS GUARD ASS'Y

desc: ENSEMBLE DE GARDE

1шт.

1

2197-1013

SUPPORT;MOUNT(R)

desc: SUPPORT

1шт.

2

2197-1014

SUPPORT;MOUNT(L)

desc: SUPPORT

1шт.

3

2623-1221

F.O.P.S GUARD

desc: GARDE

1шт.

4

S0521351

BOLT M16X2.0X35

desc: BOULON A 6 PANS

6шт.

5

S5102901

WASHER;SPRING M16

desc: RONDELLE ELASTIQUE

14шт.

6

S0565561

BOLT M16X2.0X65

desc: BOULON A 6 PANS

8шт.

7

2621-3641

COVER

desc: COUVERCLE

1шт.

8

2142-1103

GUARD;FRONT

desc: PROTECTION

1шт.

9

S0558853

BOLT M10X1.5X65

desc: BOULON A 6 PANS

6шт.

10

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

14шт.

11

2197-1531

SUPPORT

desc: SUPPORT

1шт.

12

S0512053

BOLT M10X1.5X25

desc: BOULON A 6 PANS

8шт.

13

S5010613

WASHER;PLAIN M10

desc: RONDELLE PLATE

8шт.

14

S0515353

BOLT M12X1.75X35

desc: BOULON A 6 PANS

3шт.

15

S5102703

WASHER;SPRING M12

desc: RONDELLE ELASTIQUE

3шт.

16

S5010713

WASHER;PLAIN M12

desc: RONDELLE PLATE

3шт.
