Запчасти Doosan Daewoo BOOM PIPING-11M OPTION PARTS

-

2400-1744

PIPING;SUPER LONG BOOM

SC: D

-2шт.

1

2184-1081D7

HOSE 2-1"6000PSI-1050L

desc: TUYAU FLEXIBLE

4шт.

2

2181-9081

FLANGE;SPLIT

desc: FLASQUE EN DEUX PARTIES

16шт.

3

S2215461

BOLT;SOCKET M12X1.75X40

desc: BOULON A 6 PANS CREUX

32шт.

4

2180-1026D19

O-RING SAE 1 "

desc: JOINT TORIQUE

8шт.

5

2140-1165

PIPE;BUCKET DUMP(OPT.)

desc: TUYAU

1шт.

6

2140-1164

PIPE;BUCKET CROWD(OPT.)

desc: TUYAU

1шт.

7

2140-1169

PIPE;ARM DUMP(OPT.)

desc: TUYAU

1шт.

8

2140-1168

PIPE;ARM CROWD(OPT.)

desc: TUYAU

1шт.

9

2140-1162

PIPE;BUCKET CROWD & DUMP(OPT.)

desc: TUYAU

2шт.

10

2140-1163

PIPE;ARM CROWD & DUMP(OPT.)

desc: TUYAU

2шт.

11

2140-1215

PIPE

desc: TUYAU

1шт.

12

2140-1216

PIPE

desc: TUYAU

1шт.

13

2140-1217

PIPE

SERIAL: 1-48

2шт.

13

2140-1217A

PIPE

SERIAL: 49

2шт.

14

2140-1218

PIPE

desc: TUYAU

1шт.

15

2140-1219

PIPE

desc: TUYAU

1шт.

16

2184-1081D97

HOSE 1.25".1100L

desc: TUYAU FLEXIBLE

2шт.

17

2180-1026D23

O-RING SAE 1 1/4"

desc: JOINT TORIQUE

14шт.

18

S2218761

BOLT;SOCKET M14X2.0X55

desc: BOULON A 6 PANS CREUX

48шт.

19

2124-1578

CLAMP;PIPE

desc: ATTACHE DE TUYAU

28шт.

20

2161-2070

RUBBER

SERIAL: 1-221

56шт.

20

2161-2070A

RUBBER

SERIAL: 222

56шт.

21

S0562761

BOLT M14X2.0X40

desc: BOULON A 6 PANS

28шт.

22

S5102803

WASHER;SPRING M14

desc: RONDELLE ELASTIQUE

28шт.

23

2114-1180D15

SHIM

desc: CALE

14шт.

24

2124-1293

CLAMP;PIPE

desc: ATTACHE DE TUYAU

8шт.

25

S0561153

BOLT M12X1.75X70

desc: BOULON A 6 PANS

16шт.

26

S5102703

WASHER;SPRING M12

desc: RONDELLE ELASTIQUE

16шт.

27

2181-9086

FLANGE;SPLIT 1.25" 6000psi

desc: FLASQUE EN DEUX PARTIES

8шт.

28

S2218561

BOLT;SOCKET M14X2.0X45

desc: BOULON A 6 PANS CREUX

8шт.

29

S5110701

WASHER;SPRING M12

SERIAL: 4

32шт.
