Запчасти Doosan Daewoo CABIN RISER ASSY(1) MAGNETIC PARTS

-

2622-1384

CABIN RISER ASS'Y

desc: ECHILLE DE CABINE

-2шт.

7

S0565461

BOLT M16X2.0X60

desc: BOULON A 6 PANS

4шт.

8

S5102901

WASHER;SPRING M16

desc: RONDELLE ELASTIQUE

8шт.

9

S5010913

WASHER;PLAIN M16

desc: RONDELLE PLATE

16шт.

10

2197-1128

SUPPORT

desc: SUPPORT

1шт.

11

2197-1578

SUPPORT

desc: SUPPORT

1шт.

12

S0565161

BOLT M16X2.0X45

desc: BOULON A 6 PANS

1шт.

13

S4012933

NUT M16X2.0

desc: ECROU

8шт.

14

2543-9021

CONTROLLER;MAGNET

desc: MODULE DE COMMANDE

1шт.

15

2549-9078

SWITCH;SAFETY

desc: INTERRUPTEUR

1шт.

16

S0512053

BOLT M10X1.5X25

desc: BOULON A 6 PANS

4шт.

17

S5010613

WASHER;PLAIN M10

desc: RONDELLE PLATE

8шт.

18

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

4шт.

19

S4012633

NUT M10X1.5

desc: ECROU

4шт.

20

2621-3161

COVER

desc: COUVERCLE

1шт.

23

2549-9079

SWITCH;LIFT/DROP

desc: INTERRUPTEUR

1шт.

24

2120-2108

BOLT 5/16"-20

desc: BOULON A 6 PANS

4шт.

25

S5102503

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE

4шт.

26

2195-3936

BRACKET

desc: SUPPORT

1шт.

27

2160-1004D13

BUSHING;RUBBER

desc: GARNISSAGE CAOUTCHOUC

2шт.

32

2621-3684

COVER

desc: COUVERCLE

1шт.

33

2197-1584

BRACKET

desc: SUPPORT

1шт.

34

2621-3687

COVER;OPT

desc: COUVERCLE

1шт.
