Запчасти Doosan Daewoo INTAKE MANIFOLD ENGINE PARTS

101

65.08201-5250A

MANIFOLD;INTAKE

desc: COLLECTEUR

2шт.

102

06.01923-3132

BOLT ASS'Y M8X110

desc: BOULON A 6 PANS

8шт.

103

06.01923-3129

BOLT ASS'Y M8X90

desc: BOULON A 6 PANA

8шт.

104

65.08902C0078

GASKET;INTAKE MANIFOLD

desc: JOINT

8шт.

105

65.08202-5039

PIPE;EQUALIZING

desc: TUYAU

1шт.

106

06.01923-3226

BOLT ASS'Y M10X75

desc: BOULON A 6 PANS

4шт.

107

06.01013-9222

BOLT;HEX. M10X1.5X85

desc: BOULON A 6 PANS

2шт.

108

06.15010-2312

WASHER;PLAIN

desc: RONDELLE

2шт.

109

06.16731-2108

WASHER;SPRING

desc: RONDELLE

2шт.

110

65.08902A0057

GASKET

desc: JOINT

4шт.

111

65.08202-0080

FLANGE;INLET(L.H.)

desc: BRIDE

1шт.

114

65.08202-0225

FLANGE;INLET(R.H.)

desc: BRIDE

1шт.

115

06.01923-3218

BOLT ASS'Y M10X35

desc: BOULON A 6 PANS

6шт.

117

65.08220-0002A

PIPE;CONNECTION

desc: TUYAU

2шт.

118

65.96501-0058

O-RING

desc: JOINT TORIQUE

4шт.

119

65.90310-0050B

SCREW. PLUG M20X1.5

desc: TUYAU

2шт.

120

06.56190-0715

SEAL RING A20X26

desc: JOINT TORIQUE

2шт.

121

65.90310-0048

PLUG SCREW M10X1.5

desc: SUPPORT

1шт.

122

06.56180-0714

SEAL RING A10X15

desc: BOULON A 6 PANS

1шт.
