Запчасти Doosan Daewoo FUEL PIPING ENGINE PARTS

101

65.10101-7068

NOZZLE & HOLDER ASS'Y

SERIAL: 991101

8шт.

101

65.10101-7084

NOZZLE & HOLDER ASS'Y

SERIAL: 991102

8шт.

102

9134-366

HOLDER

SERIAL: 991101

1шт.

102

65.10102-0119

NOZZLE

SERIAL: 991102

1шт.

103

65.10102-0008

NOZZLE

desc: . VIS

1шт.

104

65.98701-0075

RING;SEAL

desc: JOINT

8шт.

105

65.10108-0003C

SCREW;PRESSURE

desc: VIS

8шт.

106

65.98701-0006

SEAL;NOZZLE HOLDER HOLE

desc: PARE-POUSSIERES

8шт.

201

06.56190-0706

RING;SEAL

desc: BAGUE D'ETANCHEITE

2шт.

202

06.78144-2204

SCREW;HOLLOW

desc: VIS CREUSE

1шт.

203

65.96341-0100

HOSE;FUEL

desc: TUYAU A GAZOLE

1шт.

204

06.56190-0706

RING;SEAL

desc: BAGUE D'ETANCHEITE

2шт.

205

06.78144-2204

SCREW;HOLLOW

desc: VIS CREUSE

1шт.

206

06.78144-2204

SCREW;HOLLOW

desc: VIS CREUSE

1шт.

207

06.56190-0706

RING;SEAL

desc: BAGUE D'ETANCHEITE

2шт.

208

65.96341-0100

HOSE;FUEL

desc: TUYAU A GAZOLE

1шт.

209

06.56190-0706

RING;SEAL

desc: BAGUE D'ETANCHEITE

2шт.

210

06.78144-2204

SCREW;HOLLOW

desc: VIS CREUSE

1шт.

211

06.56190-0706

RING;SEAL

desc: BAGUE D'ETANCHEITE

2шт.

212

65.96341-0109

HOSE;FUEL

desc: ENSEMBLE DE TUYAU FLEXIBLE

1шт.

213

06.56180-0712

RING;SEAL

desc: BAGUE D'ETANCHEITE

6шт.

214

65.98150-0042A

SCREW;HOLLOW

desc: VIS CREUSE M8x1

3шт.

215

06.78144-2204

SCREW;HOLLOW

desc: VIS CREUSE

1шт.

216

06.56190-0706

RING;SEAL

desc: BAGUE D'ETANCHEITE

2шт.

217

65.12301-5142

PIPE;FUEL OVER FLOW

desc: CONDUITE

2шт.

218

65.96501-0348

RING;DOUBLE SEAL

desc: BAGUE D'ETANCHEITE

8шт.

219

65.98150-0080

SCREW;HOLLOW

desc: VIS CREUSE

6шт.

220

65.98150-0057

SCREW;HOLLOW

desc: VIS CREUSE

2шт.

221

65.97460-0001

BAND;TENSION

desc: COLLIER

4шт.

222

65.12301-5821A

PIPE ASS'Y;DELIVERY

desc: ENSEMBLE CONDUITES DE GAZOLE

1шт.

223

65.12301-5204A

PIPE ASS'Y;RETURN

desc: CONDUITE

1шт.

224

65.97401-5008

CLIP;PIPE

desc: COLLIER

1шт.
