Запчасти Doosan Daewoo CYLINDER HEAD ENGINE PARTS

102

65.03101-6045

CYLINDER HEAD ASS'Y

desc: ENSEMBLE CULASSE

8шт.

103

65.03101-1039

HEAD;CYLINDER

desc: . TETE DE VERIN

1шт.

105

65.03201-1040

VALVE;GUIDE

desc: . GUIDE DE SOUPAPE

2шт.

106

65.03203-0242

VALVE;SEAT(INTAKE)

desc: . SIEGE

1шт.

107

65.03203-0184

VALVE;SEAT(EXHAUST)

desc: . SIEGE

1шт.

108

65.91606-0037

PLUG;CORE HOLE

desc: . BOUCHON B28D

1шт.

109

65.91606-0041

PLUG;CORE HOLE

desc: . BOUCHON

1шт.

110

06.08022-2207

SCREW;PLUG M22X1.5

desc: . BOUCHON A VIS

1шт.

121

65.90020-0268

BOLT;CYLINDER HEAD

desc: VIS DE CULASSE

16шт.

122

65.90020-0269

BOLT;CYLINDER HEAD

desc: VIS DE CULASSE

24шт.

123

65.90020-0270

BOLT;CYLINDER HEAD

desc: VIS DE CULASSE

8шт.

124

65.03901-0015

GASKET;CYLINDER HEAD

desc: JOINT DE CULASSE

8шт.

201

65.03401-0045A

COVER;CYLINDER HEAD

desc: COUVERCLE

7шт.

202

65.03401-0046A

COVER;CYLINDER HEAD

desc: COUVERCLE

1шт.

203

06.01923-3125

BOLT ASS'Y M8X70

desc: BOULON A 6 PANS

16шт.

204

06.01923-3120

BOLT ASS'Y M8X45

desc: BOULON A 6 PANS

8шт.

205

65.01810-5006

FILLER CAP ASS'Y

desc: VIBREUR

1шт.

208

65.03905-0015B

GASKET;CYLINDER HEAD COVER

desc: JOINT

8шт.

301

65.97801-0148

PLATE;CAUTION

SC: D

2шт.

302

65.97871-0473

PLATE;NAME(COMPANY)

SC: D

1шт.

304

65.97801-0070

PLATE;CAUTION

SC: D

1шт.
