Запчасти Doosan Daewoo CYLINDER BLOCK ENGINE PARTS

102

65.01101-6819C

CYLINDER BLOCK ASS'Y

desc: BLOC CYLINDRES

1шт.

105

65.01101-6806C

CYLINDER BLOCK

SC: D

1шт.

107

65.01105-6014

BEARING CAP ASS'Y(TH)

SC: D

1шт.

108

65.01105-1162

CAP;BEARING

SC: D

1шт.

109

65.91301-0071

PIN

desc: .. TIGE

2шт.

110

65.01105-6013

BEARING CAP ASS'Y

SC: D

4шт.

111

06.22022-3061

PIN;DOWEL 8H8X18

desc: .. TIGE

2шт.

112

65.01105-1162

CAP;BEARING

SC: D

1шт.

113

65.90020-0293A

BOLT;BEARING CAP(MAIN)

desc: . BOULON A 6 PANS

10шт.

114

06.01494-4316

BOLT;HEX. M12X1.5X85

desc: . BOULON A 6 PANS

10шт.

115

65.04410-0018

BUSH;CAMSHAFT

SC: B

1шт.

116

65.04410-0078

BUSH;CAMSHAFT

SC: B

4шт.

117

65.91606-0039

PLUG;CORE

desc: . BOUCHON B28D

10шт.

118

65.91606-0037

PLUG;CORE HOLE

desc: . BOUCHON B28D

2шт.

119

06.15090-2319

PLUG;CORE

desc: . BOUCHON B28D

2шт.

120

65.90310-0149A

SCREW;PLUG M26X1.5

desc: . BOUCHON A VIS

6шт.

121

06.56190-0726

RING;SEAL

desc: . BAGUE D'ETANCHEITE

6шт.

122

65.90310-0132

SCREW;PLUG

desc: . BOUCHON A VIS

2шт.

123

06.56190-0718

RING;SEAL

desc: . BAGUE

2шт.

124

65.90310-0134

SCREW;PLUG

desc: . VIS

2шт.

125

06.56190-0732

RING;SEAL

desc: . CONTACT DE NIVEAU D'HUILE

2шт.

126

06.31641-0615

BALL;STEEL

desc: . BILLE

1шт.

127

06.22022-1063

PIN;DOWEL

desc: . GOUJON D'ASSEMBLAGE

2шт.

128

06.22022-3563

PIN;DOWEL

desc: . GOUJON D'ASSEMBLAGE

2шт.

131

65.90310-0135

SCREW;PLUG

desc: BOUCHON A VIS

4шт.

132

06.56190-0706

RING;SEAL A14X20

desc: BAGUE D'ETANCHEITE

4шт.

135

65.91605-0013

COVER

desc: COUVERCLE

1шт.

136

65.01110-6522

METAL;MAIN (STD)

SERIAL: 010129

4шт.

136

65.01110-6522B

METAL;MAIN (STD)

SERIAL: 010130

4шт.

136

65.01110-6523B

METAL;MAIN (0.10)

SC: OS

4шт.

136

65.01110-6524B

METAL;MAIN (0.25)

SC: OS

4шт.

137

65.01111-6522

METAL;THRUST (STD)

SERIAL: 010129

1шт.

137

65.01111-6539

METAL;THRUST (STD)

SERIAL: 010130

1шт.

138

65.90310-0131

SCREW;PLUG

desc: VIS

1шт.

139

06.56190-0713

RING;SEAL A18X24

desc: BAGUE D'ETANCHEITE

1шт.

140

65.91701-0274

PIN;LOCATING

desc: BROCHE

16шт.

141

65.90310-0134

SCREW;PLUG

desc: VIS

2шт.

142

06.56190-0732

SEAL;RING

desc: CONTACT DE NIVEAU D'HUILE

2шт.

144

65.01201-0049A

LINER;CYLINDER

desc: CHEMISE DE CYLINDRE

8шт.

145

65.96501-0059

O-RING;CYLINDER LINER UPPER

desc: JOINT TORIQUE

16шт.

146

51.96501-0412

O-RING

desc: JOINT TORIQUE

8шт.

147

65.96501-0078

O-RING (LOW)

desc: JOINT TORIQUE

8шт.

148

65.98130-0066

ADAPTER;OIL PRESS

desc: RACCORD ADAPTATEUR

1шт.

149

06.56190-0728

RING;SEAL

desc: BAGUE D'ETANCHEITE

1шт.

150

65.27441-7007

SWITCH;OIL PRESS

desc: MANOCONTACT DE PRESSION D'HUILE

1шт.

151

65.98131-0060

SCREW;CONNECTION

desc: VIS

1шт.

152

06.56190-0706

RING;SEAL

desc: BAGUE D'ETANCHEITE

9шт.

153

65.06301-5117A

C/W PIPE ASS'Y

desc: CONDUITE

1шт.

154

04.27405-0220

HOSE;RUBBER

desc: TUYAU FLEXIBLE

1шт.

155

65.97440-0045

CLAMP;HOSE

desc: COLLIER

2шт.

156

65.06312-0008

FLANGE (BLOCK-S.TANK)

desc: RACCORD

1шт.

158

06.56250-2006

GASKET(C/W PIPE FLANGE)

desc: JOINT

1шт.

159

06.01013-9213

BOLT;HEX. M10X40

desc: BOULON A 6 PANS

2шт.

160

06.16731-2108

WASHER;SPRING

desc: RONDELLE

2шт.

161

65.90310-0140

SCREW;PLUG M16x1.5

desc: BOUCHON

2шт.

162

06.56190-0708

RING;SEAL

desc: BAGUE D'ETANCHEITE A16X20

2шт.

163

65.01601-5063

OIL SPRAY NOZZLE ASS'Y

desc: ENSEMBLE REFROIDISSEUR D'HUILE

8шт.

173

65.90001-0129

BOLT;HEX. M6X28

desc: BOULON A 6 PANS

16шт.

174

06.16044-0208

WASHER;SPRING

desc: RONDELLE PLATE

16шт.

175

65.01601-2016A

FLANGE ASS'Y

desc: BRIDE

8шт.

176

65.96601A0237

GASKET

desc: JOINT

8шт.

177

65.98150-0051

SCREW;HOLLOW

desc: VIS CREUSE

8шт.

178

65.19202-0009D

HOOK;LIFTING

desc: SUPPORT

1шт.

179

06.01283-7719

BOLT;HEX. M20X40

desc: BOULON A 6 PANS

1шт.

180

06.16731-2113

WASHER;SPRING

desc: RONDELLE ELASTIQUE

1шт.

181

06.01914-3215

BOLT ASS'Y M10X25

desc: BOULON A 6 PANS

1шт.

182

65.01803-0007

PLATE;BAFFLE

desc: PLAQUE

1шт.

201

65.41530-0148

BRACKET;ENGINE MOUNTING(FR)

desc: SUPPORT

2шт.

202

06.01914-3320

BOLT ASS'Y M12X45

desc: BOULON A 6 PANS

8шт.

331

65.05701-0141A

PIPE;OIL SEPARATOR

desc: CONDUITE

1шт.

332

06.56190-0739

RING;SEAL

desc: CONTACT DE NIVEAU D'HUILE

1шт.
