Запчасти Doosan Daewoo AIR COMPRESSOR MOUNTING ENGINE PARTS

101

65.54300-6007

MOUNTING PLATE ASS'Y

SERIAL: 990205

1шт.

101

65.54300-6008

MOUNTING PLATE ASS'Y

SERIAL: 990206

1шт.

102

65.54302-5009

PLATE;MOUNTING

desc: . PLAQUE

1шт.

103

65.54302-0005

PLATE;SLIDING

desc: . PLAQUE LATERALE

1шт.

104

65.54306-0006

PLATE;CLAMPING

desc: . PLAQUE

1шт.

105

06.01284-7512

BOLT;HEX. M10X25

desc: . BOULON A 6 PANS

2шт.

106

06.16731-2108

WASHER;SPRING A10

desc: . RONDELLE ELASTIQUE

2шт.

107

65.97480-0148

BRACKET;TENSION

desc: . SUPPORT

1шт.

108

06.01283-6916

BOLT;HEX. M6X28

desc: . BOULON A 6 PANS

2шт.

109

06.16731-2105

WASHER;SPRING A6

desc: . RONDELLE ELASTIQUE

2шт.

110

65.90441-0010

BOLT;TENSION M10X65

desc: . BOULON A 6 PANS

1шт.

111

06.11063-8214

NUT;HEX. M10

desc: . ECROU

1шт.

112

65.96801-0066

V-BELT;AIRCON(1X17X1300)

desc: COURROIE

1шт.

113

65.96801-0115

V-BELT.ALT.(L-1850)

desc: JOINT

1шт.

201

65.19103-0047

SUPPORT

desc: SUPPORT D'ALTERNATEUR

1шт.

202

06.01013-7122

BOLT;HEX

desc: BOULON A 6 PANS

1шт.

203

06.11063-8215

NUT;HEX

desc: ECROU

1шт.

204

06.16731-2108

WASHER;SPRING A10

desc: RONDELLE ELASTIQUE

1шт.
