Запчасти Doosan Daewoo PISTON ENGINE PARTS

101

65.02401-6198

CONNECTING-ROD ASS'Y

SERIAL: 000120

8шт.

101

65.02401-6019

CONNECTING-ROD ASS'Y

SERIAL: 000121

8шт.

102

65.02401-0012

CONNECTING-ROD

SC: D

1шт.

103

65.02405-1008

BUSH;CONNECTING ROD

SC: D

1шт.

106

65.02411-0008

BOLT;CONNECTING ROD

desc: . BOULON A 6 PANS

2шт.

108

65.02410-0100

METAL;CON-ROD(UPPER-STD)

desc: PALIER

8шт.

108

65.02410-0101

METAL;CON-ROD(UPPER-0.1)

SC: US

8шт.

108

65.02410-0102

METAL;CON-ROD(UPPER-0.25)

SC: US

8шт.

109

65.02410-0200

METAL;CON-ROD(LOWER-STD)

desc: PALIER

8шт.

109

65.02410-0201

METAL;CON-ROD(LOWER-0.1)

SC: US

8шт.

109

65.02410-0202

METAL;CON-ROD(LOWER-0.25)

SC: US

8шт.

201

65.02501-0771

PISTON(DV15T)

SERIAL: 960826

8шт.

201

65.02501-0771C

PISTON(DV15T)

SERIAL: 960827

8шт.

202

65.02502-0081

PIN;PISTON

desc: AXE DE PISTON

8шт.

203

65.90810-0011

RING;SNAP

desc: CIRCLIP

16шт.

204

65.02503-0672

RING;TOP

desc: BAGUE

8шт.

205

65.02503-0108

RING;PISTON OIL(2ND)

desc: BAGUE

8шт.

206

65.02503-0109

RING;PISTON OIL

desc: SEGMENT DE PISTON

8шт.
