Запчасти Doosan Daewoo SWING DEVICE BODY PARTS

-

2401-1209

SWING DEVICE

SERIAL: 238

-2шт.

1

2401-1280

SWING DEVICE SUB ASS'Y

SERIAL: 238-261

2шт.

1

2401-1280A

SWING DEVICE SUB ASS'Y

SERIAL: 262-282

2шт.

1

2401-1280B

SWING DEVICE SUB ASS'Y

SERIAL: 283-311

2шт.

1

2401-1280C

SWING DEVICE SUB ASS'Y

SERIAL: 312-312

2шт.

1

2401-1280E

SWING DEVICE SUB ASS'Y

SERIAL: 313

2шт.

1-1

2401-9304

SWING MOTOR

desc: . SYSTEME D'ORIENTATION

1шт.

1-2

2404-6010B

REDUCTION GEAR

SERIAL: 238-261

1шт.

1-2

2404-6010C

REDUCTION GEAR

SERIAL: 262-282

1шт.

1-2

2404-6010D

REDUCTION GEAR

SERIAL: 283-312

1шт.

1-2

2404-6010E

REDUCTION GEAR

SERIAL: 313

1шт.

1-3

2181-1113D2

REDUCER

desc: . REDUCTEUR

1шт.

1-4

2186-9001

COCK

SERIAL: 238-311

1шт.

1-4

2186-9003

COCK

SERIAL: 312

1шт.

2

S0570161

BOLT M20X2.5X65

desc: BOULON A 6 PANS

22шт.

3

2114-9012

WASHER;HARD

desc: RONDELLE ELASTIQUE

22шт.

4

2404-1056

GEAR;PINION

desc: PIGNON

2шт.

5

2403-4001A

COVER

desc: COUVERCLE

2шт.

6

2120-4006

BOLT M16X2.0X40

desc: BOULON A 6 PANS

4шт.

7

S5102901

WASHER;SPRING M16

desc: RONDELLE ELASTIQUE

4шт.

8

2126-9001

WIRE

desc: CABLE

2шт.

9

2123-1916

PIN;BLOCK

desc: BROCHE

2шт.

10

S6710042

NIPPLE;GREASE

desc: GRAISSEUR

2шт.

11

2181-4112

ADAPTER PT1/8-PF1/4

desc: RACCORD

4шт.

12

2184-1046D148

HOSE PF1/4-1450L

desc: TUYAU FLEXIBLE

2шт.

14

2184-9086

HOSE;VINYL

SERIAL: 238-311

2шт.

14

184-00016

HOSE;VINYL

SERIAL: 312

2шт.

15

S8450006

CLAMP;HOSE

SERIAL: 238-311

2шт.

15

S8450012

CLAMP;HOSE

SERIAL: 312

2шт.

16

2124-1084D3

CLIP;BAND

desc: ATTACHE

4шт.

17

2182-1662

PIPE

desc: TUYAU

2шт.

18

2119-1063A

CAP

desc: CHAPEAU

2шт.

19

2181-1913D24

REDUCER PF1/2-PF3/4

desc: REDUCEUR

2шт.
