Запчасти Doosan Daewoo MAIN PIPING(5) BODY PARTS

-

2400-1677

MAIN PIPING(5)

SC: D

-2шт.

7

2181-9078

FLANGE;SPLIT 1" 5000psi

desc: COLLIER A BRIDE(1")

8шт.

9

2181-9086

FLANGE;SPLIT 1.25" 6000psi

SERIAL: 1-306

8шт.

13

2180-1026D19

O-RING SAE1"

SERIAL: 1-246

4шт.

13

2180-1026D19

O-RING SAE1"

SERIAL: 247

8шт.

14

2180-1026D23

O-RING SAE 1 1/4"

SERIAL: 1-246

8шт.

14

2180-1026D23

O-RING SAE 1 1/4"

SERIAL: 247-306

4шт.

27

2184-1124D105

HOSE 1"-1.25 1550L

SERIAL: 1-3

1шт.

27

2184-1124D109

HOSE 1350L

SERIAL: 4-306

1шт.

27

2184-1124D48

HOSE 1330L

SERIAL: 307

1шт.

28

2184-1124D107

HOSE 1"-1.25 1850L

SERIAL: 1-3

1шт.

28

2184-1124D111

HOSE 1650L

SERIAL: 4-306

1шт.

28

2184-1124D202

HOSE 1650L

SERIAL: 307

1шт.

29

2184-1124D106

HOSE 1"-1.25 1750L

SERIAL: 1-3

1шт.

29

2184-1124D110

HOSE 1600L

SERIAL: 4-306

1шт.

29

2184-1124D201

HOSE 1600L

SERIAL: 307

1шт.

30

2184-1124D104

HOSE 1"-1.25 1450L

SERIAL: 1-3

1шт.

30

2184-1124D108

HOSE 1300L

SERIAL: 4-306

1шт.

30

2184-1124D200

HOSE 1300L

SERIAL: 307

1шт.

45

S2218661

BOLT;SOCKET M14X2.0X50

SERIAL: 1-3

16шт.

45

S2218561

BOLT;SOCKET M14X2.0X45

SERIAL: 4-246

16шт.

50

S2212361

BOLT;SOCKET M10X1.5X35

SERIAL: 1-3

16шт.

50

S2212261

BOLT;SOCKET M10X1.5X30

SERIAL: 4

16шт.

53

S5110801

WASHER;SPRING M14

SERIAL: 1-246

32шт.

53

S5110801

WASHER;SPRING M14

SERIAL: 247-306

16шт.

55

S5110601

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

16шт.

60

S2215461

BOLT;SOCKET M12X1.75X40

SERIAL: 247-306

16шт.

64

2183-4691C

PIPE;ROTARY JOINT

SERIAL: 1-246

2шт.

64

2183-4691E

PIPE;ROTARY JOINT

SERIAL: 247-306

2шт.

65

2183-3815B

PIPE;ROTARY JOINT

SERIAL: 1-246

2шт.

65

2183-3815C

PIPE;ROTARY JOINT

SERIAL: 247-306

2шт.

66

S2218761

BOLT;SOCKET M14X2.0X55

SERIAL: 1-306

16шт.

82

S5110701

WASHER;SPRING

SERIAL: 247

16шт.

83

S2215361

BOLT;SOCKET M12X1.75X35

SERIAL: 307

16шт.

84

2181-9084A

FLANGE;SPLIT

SERIAL: 307

8шт.
