Запчасти Doosan Daewoo AIR CONDITIONER BODY PARTS

-

2920-1061

COOLER & HEATER ASS'Y

desc: REFRIGERATION

1шт.

1

2208-6010A

COMPRESSOR M-5.B-TYPE

SERIAL: 1-3

1шт.

1

2208-6010B

COMPRESSOR M-5.B-TYPE

SERIAL: 4

1шт.

2

S0509053

BOLT M8X1.25X25

desc: BOULON A 6 PANS

7шт.

3

S5102503

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE

7шт.

4

S5010513

WASHER;PLAIN M8

desc: RONDELLE PLATE

2шт.

6

2185-1352A

HOSE;COMPRESSOR

desc: TUYAU FLEXIBLE COMPRESSEUR

1шт.

7

2180-1219

WASHER;SEAL

desc: RONDELLE D'ETANCHEITE

2шт.

8

S2212261

BOLT;SOCKET M10X1.5X30

desc: BOULON A 6 PANS CREUX

3шт.

9

S5110601

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

3шт.

10

S5020603

WASHER;PLAIN M10

desc: RONDELLE PLATE

3шт.

11

2520-6003

CONDENSER ASS'Y

SERIAL: 1-206

1шт.

11

2520-6003A

CONDENSER ASS'Y

SERIAL: 207

1шт.

12

2197-1050

BRACKET;CONDENSER

SERIAL: 1-236

2шт.

12

2197-1050A

BRACKET;CONDENSER

SERIAL: 237

2шт.

13

S0553553

BOLT M6X1.0X45

desc: BOULON A 6 PANS

4шт.

14

S5102303

WASHER;SPRING M6

desc: RONDELLE ELASTIQUE

10шт.

15

S5010313

WASHER;PLAIN M6

desc: RONDELLE PLATE

10шт.

16

S4012333

NUT M6X1.0

desc: ECROU

4шт.

17

2185-1371D3

HOSE;LIQUID(1) L2700

desc: TUYAU FLEXIBLE LIQUIDE

1шт.

18

2185-1369D6

HOSE;LIQUID(2) L4800

desc: TUYAU FLEXIBLE LIQUIDE

1шт.

19

2204-6032

RECEIVER DRIER

desc: RESERVOIR DESSICATEUR

1шт.

20

2514-6001

HOLDER;RECEIVER DRIER

desc: POSSESSEUR

1шт.

21

S0504853

BOLT M6X1.0X20

desc: BOULON A 6 PANS

6шт.

22

2920-9031A

AIR HANDING UNIT

SERIAL: 1-3

1шт.

22

2920-9031B

AIR HANDING UNIT

SERIAL: 4-299

1шт.

22

2920-9031C

AIR HANDING UNIT

SERIAL: 300

1шт.

22A

2545-6020

RESISTOR ASS'Y

desc: . RESISTANCE

1шт.

22B

2538-6012

BLOWER MOTOR

desc: . MOTEUR

1шт.

22C

2547-6030

THERMISTOR

desc: . THERMOSTAT

1шт.

22D

2920-6121

EVAPORATOR CORE

desc: . CHAUFFAGE

1шт.

22E

2920-6120

HEATER CORE ASS'Y

desc: . CHAUFFAGE

1шт.

23

2191-1374D12

PLATE

desc: PLAQUE

4шт.

24

S0509053

BOLT M8X1.25X25

desc: BOULON A 6 PANS

4шт.

25

S5102503

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE

4шт.

26

2114-1058D29

WASHER Ґх26/Ґх9

desc: RONDELLE PLATE

4шт.

27

2549-1132D2

SWITCH;AIRCON

desc: INTERRUPTEUR

1шт.

28

2543-9027

CONTROLLER;AIRCON

desc: MODULE DE COMMANDE

1шт.

29

S3450583

SCREW M4X0.7X12

desc: VIS

2шт.

30

S5100103

WASHER;SPRING M4

desc: RONDELLE ELASTIQUE

2шт.

39

2124-1509D6

CLIP Ґх42-M8

desc: ATTACHE

3шт.

40

S4012533

NUT M8X1.25

desc: ECROU

3шт.

41

S5102503

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE

3шт.

42

2124-1084D3

CLIP;BAND L250

desc: ATTACHE

15шт.
