Запчасти Doosan Daewoo TRACK SHOE ASSY-800G OPTION PARTS

-

2273-7079

TRACK SHOE ASS'Y

SC: D

-2шт.

1

2273-6071D2

TRACK SHOE ASS'Y-800G

desc: ENSEMBLE MAILLON DE CHAINES

2шт.

1-1

2272-6185

TRACK LINK ASS'Y

desc: . ENSEMBLE MAILLON DE CHAINES

1шт.

1-1A

2272-6188

LINK(R.H.)

desc: .. PIECE DE JONCTION

50шт.

1-1B

2272-6187

LINK(L.H.)

desc: .. PIECE DE JONCTION

50шт.

1-1C

2110-6079

BUSHING

desc: .. COUSSINET

49шт.

1-1D

2110-6080

BUSHING;MASTER

desc: .. DOUILLE PRINCIPALE

1шт.

1-1E

2123-6105

PIN

desc: .. GOUPILLE

49шт.

1-1F

2123-6106

PIN;MASTER

desc: .. GOUPILLE

1шт.

1-1G

2114-6048

SPACER

desc: .. BAGUE

2шт.

1-1H

2180-6091

SEAL;DUST

desc: .. BAGUE

98шт.

1-2

2273-6073D2

SHOE;TRACK-800§® 20t

desc: . SABOT

50шт.

1-3

2120-6030

BOLT;TRACK M22X1.5

desc: . BOULON A 6 PANS

200шт.

1-4

2121-6037

NUT;TRACK M22X1.5

desc: . ECROU

200шт.

2

2625-1220D7

BRACKET

desc: SUPPORT

4шт.

3

2190-3555

PLATE;NAME(KOREA)

desc: PLAQUE SIGNALETIQUES

1шт.

4

S0558253

BOLT M10X1.5X35

desc: BOULON A 6 PANS

16шт.

5

S5102603

WASHER;SPRING

desc: RONDELLE ELASTIQUE

16шт.
