1
65.02101-7541A
CRANK SHAFT ASS'Y
SERIAL: 020830
1шт.
1
65.02101-7541B
CRANK SHAFT ASS'Y
SERIAL: 020831
1шт.
2
65.02101-7054A
CRANK SHAFT ASS'Y(3~7)
SERIAL: 020830
1шт.
2
65.02101-7054B
CRANK SHAFT ASS'Y(3~7)
SERIAL: 020831
1шт.
3
65.02101-0054
SHAFT;CRANK
SERIAL: 020830
1шт.
3
65.02101-0054A
SHAFT;CRANK
SERIAL: 020831
1шт.
4
65.02110-0014
WEIGHT;BALANCE
SERIAL: 020830
4шт.
4
65.02110-0014E
WEIGHT;BALANCE
SERIAL: 020831
4шт.
5
65.02110-0013
WEIGHT;BALANCE
SERIAL: 020830
4шт.
5
65.02110-0013E
WEIGHT;BALANCE
SERIAL: 020831
4шт.
6
65.90430-0012B
BOLT;CRANK SHAFT
desc: .. BOULON A 6 PANS
8шт.
7
65.90430-0013B
BOLT;CRANK SHAFT
desc: .. BOULON A 6 PANS
8шт.
8
65.02101-0057
CRANK SHAFT ASS'Y
SERIAL: 020830
1шт.
8
65.02101-0057A
CRANK SHAFT ASS'Y
SERIAL: 020831
1шт.
9
65.02101-0060
CRANK SHAFT ASS'Y
SERIAL: 020830
1шт.
9
65.02101-0060A
CRANK SHAFT ASS'Y
SERIAL: 020831
1шт.
10
65.02115-0008B
GEAR;CRANK SHAFT
desc: PIGNON
1шт.
11
06.22022-0912
PIN;DOWEL
desc: GOUPILLE D'AJUSTAGE
1шт.
12
65.01110-6055A
METAL;MAIN STD
desc: COUSSINET COTE STD
7шт.
12
65.01110-6068A
METAL;MAIN 0.25
SC: US
7шт.
12
65.01110-6069A
METAL;MAIN 0.50
SC: US
7шт.
12
65.01110-6070A
METAL;MAIN 0.75
SC: US
7шт.
13
65.01150-0017A
WASHER;THRUST(UPR.) STD
desc: RONDELLE DE BUTEE(HAUT) STD
2шт.
13
65.01150-0048A
WASHER;THRUST(UPR.) 0.25
SC: OS
2шт.
13
65.01150-0049A
WASHER;THRUST(UPR.) 0.50
SC: OS
2шт.
14
65.01150-0018B
WASHER;THRUST(LOW.) STD
desc: RONDELLE DE BUTEE(BAS) STD
2шт.
14
65.01150-0052B
WASHER;THRUST(LOW.) 0.25
SC: OS
2шт.
14
65.01150-0053B
WASHER;THRUST(LOW.) 0.50
SC: OS
2шт.
15
65.02201-7032
DAMPER;VIBRATION
desc: VOLANT
1шт.
16
06.01913-3215
BOLT ASS'Y M10X25
desc: BOULON A 6 PANS
6шт.
17
65.02601-0180
PULLEY;V-BELT
desc: POULLIE
1шт.
18
65.90720-0022
WASHER
SERIAL: 010601
1шт.
18
REP_PNO: 06.02106-0622
-1шт.
18
65.90701-0088
WASHER
SERIAL: 010602
1шт.
19
06.02106-0623
BOLT;SOCKET HEAD
desc: BOULON A 6 PANS CREUX
8шт.
19
06.02106-0622
BOLT;SOCKET HEAD
desc: BOULON A 6 PANS CREUX
8шт.
20
65.02301-5103
FLYWHEEL ASS'Y
desc: VOLANT
1шт.
21
65.02301-0249
FLYWHEEL
desc: . VOLANT
1шт.
22
65.02310-0011B
GEAR;STARTER RING
desc: . COURONNE DENTEE
1шт.
23
06.16731-2110
WASHER;SPRING
desc: RONDELLE ELASTIQUE
8шт.
24
65.90001-0084
BOLT;HEX
desc: BOULON A 6 PANS
8шт.
25
06.22022-1010
PIN;DOWEL
desc: GOUPILLE D'AJUSTAGE
1шт.
