Запчасти Doosan Daewoo INTAKE & EXHAUST MANIFOLD ENGINE PARTS

1

06.06226-0811

BOLT;STUD M10X45

SERIAL: 991110

6шт.

1

65.90201-0094

BOLT;STUD M10X45

SERIAL: 991111

6шт.

2

65.90201-0154

BOLT;STUD M12X1.5X10

desc: GOUJON

6шт.

3

65.08901A0012

GASKET(EXH. MFD)

desc: JOINT DE COLLECTEUR

6шт.

4

65.08100-6061

EXHAUST MANIFOLD ASS'Y

desc: COLLECTEUR

1шт.

5

65.08101-0181A

MANIFOLD(FF)

desc: . COLLECTEUR

1шт.

6

65.08101-0530

MANIFOLD(CENTER)

desc: . COLLECTEUR

1шт.

7

65.08101-0183A

MANIFOLD(RR)

desc: . COLLECTEUR

1шт.

8

65.08105-0001

RING;SEAL(EXH. MANIFOLD)

desc: . BAGUE D'ETANCHEITE

4шт.

10

06.15010-2312

WASHER 10.5

desc: RONDELLE

12шт.

11

06.11063-8215

NUT;HEX. M10

desc: ECROU

22шт.

13

65.09100-7191

TOURBO CHARGER ASS'Y

desc: TURBO CHARGER

1шт.

14

65.96601-0046

GASKET;OIL DELIVERY

desc: JOINT

1шт.

15

65.05701-5661

PIPE;OIL(B/L-T/C)

desc: TUYAU D'HUILE

1шт.

16

65.09901-0025

GASKET;T/C

desc: JOINT

1шт.

17

65.05903-0030

GASKET(OIL RETURN)

SERIAL: 030205

1шт.

17

65.96601-0012

GASKET(OIL RETURN)

SERIAL: 030206

1шт.

18

65.05701-5662

PIPE;T/C OIL RETURN

SERIAL: 030205

1шт.

18

65.05701-5442

PIPE;T/C OIL RETURN

SERIAL: 030206

1шт.

19

06.01913-3114

BOLT ASS'Y M8X22

desc: BOULON A 6 PANS

4шт.

20

06.67020-0106

CLAMP;HOSE

desc: COLLIER

2шт.

21

51.96330-0346

HOSE;RUBBER

desc: TUYAU

1шт.

22

65.05701-5654

T/C OIL RETURN PIPE

SERIAL: 030205

1шт.

22

65.05701-5443

T/C OIL RETURN PIPE

SERIAL: 030206

1шт.

23

65.96601-0045

GASKET(OIL DELIVELY)

desc: JOINT

1шт.

24

65.08201-5364B

MANIFOLD;INTAKE

desc: COLLECTEUR

1шт.

26

65.08902-0025

GASKET;INTAKE

desc: JOINT

1шт.

27

06.01923-3218

BOLT ASS'Y

desc: BOULON A 6 PANS

8шт.

28

65.09904-0008

GASKET

desc: JOINT

2шт.

29

65.26803-7028

HEATER;AIR

desc: RECHAUFFEUR D'AIR

1шт.

31

06.01913-3114

BOLT ASS'Y

desc: BOULON A 6 PANS

2шт.

34

06.01943-3317

BOLT ASS'Y

desc: BOULON A 6 PANS

2шт.

35

06.15010-2313

WASHER;PLAIN

desc: RONDELLE

2шт.

36

65.08901-0063

GASKET;T/C

desc: JOINT

1шт.

37

65.08120-5008F

SCREEN;HEAT

SERIAL: 030507

1шт.

37

65.08120-5008G

SCREEN;HEAT

SERIAL: 030508

1шт.

38

06.67020-0112

CLAMP;HOSE

desc: COLLIER A DURITE

2шт.

39

65.96301-0268

HOSE;RUBBER

desc: TUYAU

1шт.

41

65.09411-0065

PIPE;AIR

desc: CONDUITE

1шт.

48

65.98131-5008

FRANGE ASS'Y

desc: BRIDE

1шт.

49

06.01913-3113

BOLT ASS'Y M8X22

desc: BOULON A 6 PANS

2шт.

50

06.56180-0714

RING;SEAL

desc: BAGUE D'ETANCHEITE

2шт.

51

06.78144-2403

SCREW;HOLLOW

desc: VIS CREUSE

1шт.

53

06.06226-0808

BOLT;STUD M10X30

SERIAL: 030115

4шт.

53

65.90201-0076

BOLT;STUD M10X30

SERIAL: 030116

4шт.

55

06.16731-2108

WASHER;SPRING A10

desc: RONDELLE

4шт.

56

06.11063-8215

NUT;HEX. M10

SERIAL: 030115

4шт.

56

65.90535-0001

NUT;HEX. M10

SERIAL: 030116

4шт.

57

65.08301-6012

HOSE;BUCON

desc: TUYAU FLEXIBLE

1шт.

58

65.98150-0053B

SCREW;HOLLOW

desc: VIS CREUSE

1шт.

59

06.56180-0714

RING;SEAL

desc: BAGUE D'ETANCHEITE

2шт.

66

65.90201-0181

BOLT;STUD

desc: GOUJON

6шт.

67

06.16731-2108

WASHER;SPRING

desc: RONDELLE

6шт.

68

06.11063-8215

NUT;HEX

desc: ECROU

6шт.

70

06.01923-3125

BOLT ASS'Y

desc: BOULON A 6 PANS

4шт.

71

65.90201-0080

BOLT;STUD

desc: GOUJON

2шт.

72

06.16731-2108

WASHER;SPRING A10

desc: RONDELLE

2шт.

73

06.15010-2312

WASHER;PLAIN 10.5

desc: RONDELLE

2шт.

74

06.11063-8215

NUT;HEX. M10

desc: ECROU

2шт.

77

65.05740-5002

BRACKET

desc: SUPPORT

1шт.

78

06.01923-3114

BOLT ASS'Y M8X22

desc: BOULON A 6 PANS

1шт.

79

65.09501-7002

INTERCOOLER ASS'Y

desc: REFREGERATOR

1шт.

80

06.01923-3113

BOLT ASS'Y M8X20

desc: BOULON A 6 PANS

17шт.

81

65.09905-0003

GASKET

SERIAL: 030207

1шт.

81

65.09905-0006

GASKET

SERIAL: 030208

1шт.

82

06.01923-3115

BOLT ASS'Y M8X25

desc: BOULON A 6 PANS

1шт.
