Запчасти Doosan Daewoo INJECTION PUMP ENGINE PARTS

1

65.11101-7300

INJECTION PUMP ASS'Y

SERIAL: 1001-1080

1шт.

1

65.11101-7300A

INJECTION PUMP ASS'Y

SERIAL: 020219

1шт.

1

65.11101-7378

INJECTION PUMP ASS'Y

SERIAL: 020220

1шт.

1A

65.12101A7013

FEED PUMP

desc: . POMPE

1шт.

1B

134110-9420

DELIVERY VALVE

desc: . VANNE

6шт.

1C

134151-8820

PLUNGER

desc: . PLUNGEUR

6шт.

1D

131424-4420

VALVE;OVER FLOW

desc: . VANNE DE GAZOLE

1шт.

1E

65.11305-6004

COUPLING

desc: . ACCOUPLEMENT

1шт.

2

06.22022-1112

PIN;DOWEL

desc: GOUPILLE D'AJUSTAGE

2шт.

7

65.98101-0008

DOUBLE BANJO UNION ASS'Y

desc: ENSEMBLE RACCORD BANJO DOUBLE

1шт.

8

06.56190-0706

RING;SEAL

desc: BAGUE D'ETANCHEITE

2шт.

11

65.11405-0005

SHIM 0.1mm

SC: R

1шт.

11

65.11405-0006

SHIM 0.15mm

SC: R

1шт.

11

65.11405-0007

SHIM 0.2mm

SC: R

1шт.

11

65.11405-0008

SHIM 0.5mm

SC: R

1шт.

12

65.11401-0033

BRACKET;FUEL INJECTION PUMP

desc: SUPPORT

1шт.

13

06.01943-3332

BOLT ASS'Y M12X1.5X110

desc: BOULON A 6 PANS

2шт.

14

06.01943-7324

BOLT ASS'Y M12X65

desc: BOULON A 6 PANS

2шт.

18

06.01923-3228

BOLT;HEX. M10X85

desc: BOULON A 6 PANS

4шт.

19

65.05701-5313

PIPE;OIL(BLOCK - I/P)

desc: TUYAU D'HUILE

1шт.

20

65.98150-0053B

SCREW;HOLLOW

desc: VIS CREUSE

1шт.

21

06.56180-0714

RING;SEAL

desc: BAGUE D'ETANCHEITE

2шт.

22

65.05701-5624

PIPE;OIL(I/P-BLOCK)

desc: TUYAU D'HUILE

1шт.

23

06.78144-2204

SCREW;HOLLOW

desc: VIS CREUSE

2шт.

24

06.56190-0706

RING;SEAL

desc: BAGUE D'ETANCHEITE

4шт.

25

65.11405-0009

SHIM 0.1

SC: R

4шт.

25

65.11405-0010

SHIM 0.3

SC: R

4шт.

25

65.11405-0013

SHIM 0.2

SC: R

4шт.

27

06.01923-2910

BOLT ASS'Y M6X2

desc: BOULON A 6 PANS

1шт.
