Запчасти Doosan Daewoo INJECTION PIPE ENGINE PARTS

1

65.10301-7006

INJECTION PIPE ASS'Y(2~8)

desc: ENSEMBLE DE CONDUITE

1шт.

2

65.10301-5247

INJECTION PIPE NO.1

SC: D

1шт.

3

65.10301-5248

INJECTION PIPE NO.2

SC: D

1шт.

4

65.10301-5249

INJECTION PIPE NO.3

SC: D

1шт.

6

65.10301-5295

INJECTION PIPE NO.4

SC: D

1шт.

7

65.10301-5296

INJECTION PIPE NO.5

SC: D

1шт.

8

65.10301-5297

INJECTION PIPE NO.6

SC: D

1шт.

9

65.96330-0132

TUBE;FUEL OVER FLOW

desc: TUYAU

1шт.

10

65.97445-0001

CLAMP;SPRING

desc: COLLIER A RESSSORT

2шт.

11

65.12301-5165A

FUEL OVER FLOW PIPE ASS'Y

desc: CONDUITE

1шт.

12

65.98150-0042A

SCREW;HOLLOW M8X14

desc: VIS CREUSE

6шт.

13

06.56180-0712

RING;SEA

desc: BAGUE D'ETANCHEITE

12шт.

14

65.97401-6002A

3 PIPE CLIP ASS'Y

SC: D

5шт.

15

65.97401-6001A

2 PIPE CLIP ASS'Y

SC: D

2шт.

16

65.91701-0470

SPACER

desc: BAGUE D'ECARTEMENT

1шт.

17

65.91701-0533

SPACER

desc: BAGUE D'ECARTEMENT

1шт.

18

06.01913-3234

BOLT ASS'Y

desc: BOULON A 6 PANS

1шт.

19

06.01013-9221

BOLT;HEX

desc: BOULON A 6 PANS

1шт.

20

06.16731-2108

WASHER;SPRING

desc: RONDELLE

1шт.

21

06.15010-2312

WASHER;PLAIN

desc: RONDELLE

2шт.
