Запчасти Doosan Daewoo RADIATOR BODY PARTS

-

2201-1086A

ENGINE ASS'Y

SC: D

-2шт.

2

2202-9079

RADIATOR ASS'Y

SERIAL: 1001-1010

1шт.

2

2202-9079A

RADIATOR ASS'Y

SERIAL: 1011-1062

1шт.

2

2202-9079B

RADIATOR ASS'Y

SERIAL: 1063-1069

1шт.

2

2202-9079C

RADIATOR ASS'Y

SERIAL: 1070-1074

1шт.

2

2202-6129E

RADIATOR ASS'Y

SERIAL: 1075-1137

1шт.

2

2202-6129G

RADIATOR ASS'Y

SERIAL: 1138

1шт.

2-1

13D51000

RADIATOR

desc: . RADIATEUR

1шт.

2-2

13C92000

OIL COOLER

desc: . REFRIGERATOR

1шт.

2-3

13C93000

FRAME

SERIAL: 1001-1069

1шт.

2-3

13D53000

FRAME

SERIAL: 1070

1шт.

2-4

13C94000

SHROUD

SERIAL: 1001-1069

1шт.

2-4

13D54000

SHROUD

SERIAL: 1070

1шт.

2-5

13C95000

GUARD;FAN

SERIAL: 1001-1062

1шт.

2-5

13C95000A

GUARD;FAN

SERIAL: 1063

1шт.

2-6

P06A

CAP

desc: . CHAPEAU

1шт.

2-7

P04

COCK;DRAIN

desc: . ROBINET

1шт.

2-8

P03

HOSE;DRAIN

desc: . TUYAU FLEXIBLE

1шт.

2-9

P1110

BOLT M10X1.25X25

desc: . BOULON A 6 PANS

8шт.

2-10

P1108A

BOLT M10X1.25X20

desc: . BOULON A 6 PANS

8шт.

2-12

P1108B

BOLT M8X1.25X15

desc: . BOULON A 6 PANS

4шт.

2-13

P1106

BOLT M6X1.0X15

desc: . BOULON A 6 PANS

4шт.

2-14

P1306

WASHER;PLAIN M6

desc: . RONDELLE

4шт.

2-15

P1406

WASHER;SPRING M6

desc: . RONDELLE ELASTIQUE

4шт.

2-16

13C96000

WIRE;NET

desc: . CABLE

1шт.

2-17

P22

SPONGE

desc: . EPONGE

2шт.

3

S0565151

BOLT M16X2.0X45

SERIAL: 1001-1220

4шт.

3

S0565166

BOLT M16X2.0X45

SERIAL: 1221

4шт.

4

2114-1816

WASHER;HARD

SERIAL: 1001-1220

4шт.

4

2114-1816A

WASHER;HARD

SERIAL: 1221

4шт.

5

S5102901

WASHER;SPRING M16

SERIAL: 1001-1220

4шт.

5

S5102903

WASHER;SPRING M16

SERIAL: 1221

4шт.

6

S5010913

WASHER;PLAIN M16

desc: RONDELLE

4шт.

7

S0565051

BOLT M16X2.0X40

SERIAL: 1001-1220

4шт.

7

S0565066

BOLT M16X2.0X40

SERIAL: 1221

4шт.

8

2145-1267A

STAY

desc: ENTRETOISE

1шт.

9

2145-1268A

STAY

SERIAL: 1001-1062

1шт.

9

2145-1268B

STAY

SERIAL: 1063

1шт.

17

2185-1707

HOSE;WATER

desc: TUYAU FLEXIBLE

1шт.

18

2185-1740

HOSE;WATER

desc: TUYAU FLEXIBLE

1шт.

19

S8450066

CLAMP;HOSE

desc: COLLIER

4шт.
