Запчасти Doosan Daewoo PILOT PIPING(6) BODY PARTS

-

2400-2030

PILOT PIPING

SC: D

-2шт.

5

2420-9501A

VALVE;PEDAL

SERIAL: 1001-1010

1шт.

5

2420-9617A

VALVE;PEDAL

SERIAL: 1011-1089

1шт.

5

420-00030

VALVE;PEDAL

SERIAL: 1090

1шт.

18

2124-1594A

CLAMP;PLASTIC

desc: ATTACHE DE TUYAU

1шт.

19

2124-1595A

CLAMP;STEEL

desc: ATTACHE DE TUYAU

1шт.

20

S0508553

BOLT M8X1.25X14

desc: BOULON A 6 PANS

2шт.

25

S8000141

O-RING P14

desc: JOINT TORIQUE

6шт.

26

S8000111

O-RING P11

desc: JOINT TORIQUE

7шт.

27

2181-1126D14

ADAPTER PFO3/8XPF3/8

desc: RACCORD ADAPTATEUR

1шт.

30

2181-1126D36

ADAPTER PFO3/8XPF1/4

desc: RACCORD ADAPTATEUR

1шт.

31

2181-1126D89

ADAPTER PFO1/4XPF3/8

desc: RACCORD ADAPTATEUR

4шт.

34

2181-1702D5

ELBOW PFO3/8XPF3/8

desc: COUDE

1шт.

37

2181-1702D40

ELBOW PFO3/8XPF3/8

SERIAL: 1001-1140

3шт.

37

2181-1702D63

ELBOW PFO3/8XPF3/8

SERIAL: 1141-1219

3шт.

37

2181-1702D63

ELBOW PFO3/8XPF3/8

SERIAL: 1220

2шт.

40

2181-1951D7

TEE PFO3/8X2-PF1/4

desc: TE

1шт.

45

S5102503

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE

2шт.

50

2181-1950D1

PLUG

desc: BOUCHON

1шт.

63

2184-1045D98

HOSE PF1/4-380L

SERIAL: 1001-1030

1шт.

63

2184-1045D174

HOSE PF1/4-330L

SERIAL: 1031

1шт.

64

2184-1045D98

HOSE PF1/4-380L

desc: TUYAU FLEXIBLE

1шт.

65

2184-1046D229

HOSE PF3/8-3400L

desc: TUYAU FLEXIBLE

1шт.

66

2184-1046D248

HOSE PF3/8-3820L

desc: TUYAU FLEXIBLE

1шт.

67

2184-1046D229

HOSE PF3/8-3400L

desc: TUYAU FLEXIBLE

1шт.

68

2184-1046D249

HOSE PF3/8-4000L

desc: TUYAU FLEXIBLE

1шт.

125

S2212061

BOLT;SOCKET M10X1.5X25

SERIAL: 1001-1010

4шт.

125

S2212261

BOLT;SOCKET M10X1.5X30

SERIAL: 1011-1194

4шт.

125

S2212266

BOLT;SOCKET M10X1.5X30

SERIAL: 1195

4шт.

126

S5110601

WASHER;SPRING M10

SERIAL: 1001-1194

4шт.

126

S5110603

WASHER;SPRING M10

SERIAL: 1195

4шт.

128

2124-1622D3

CLIP

desc: ATTACHE

30шт.

136

S5010613

WASHER;PLAIN

SERIAL: 1011

4шт.

140

DS2281089

ELBOW PFO3/8XPF3/8

SERIAL: 1220

1шт.
