Запчасти Doosan Daewoo MAIN PIPING(2)-BOOM BODY PARTS

-

2400-1984A

MAIN PIPING

SC: D

-2шт.

14

2180-1026D23

O-RING

desc: JOINT TORIQUE

2шт.

15

2197-2161

BRACKET

desc: SUPPORT

2шт.

16

2161-2070A

RUBBER;CLAMP

desc: CAOUTCHOUC

8шт.

17

2124-1590

CLAMP;PIPE

desc: ATTACHE DE TUBE

4шт.

21

2140-1495

PIPE;BOOM UP

desc: TUYAU

1шт.

22

2140-1496

PIPE;BOOM DOWN

desc: TUYAU

1шт.

39

S0562353

BOLT M12X1.75X130

desc: BOULON A 6 PANS

1шт.

42

S0561753

BOLT M12X1.75X100

desc: BOULON A 6 PANS

1шт.

43

S0560553

BOLT M12X1.75X40

desc: BOULON A 6 PANS

4шт.

44

S2219161

BOLT;SOCKET M14X2.0X75

SERIAL: 1001-1170

4шт.

44

S2219166

BOLT;SOCKET M14X2.0X75

SERIAL: 1171

4шт.

45

S2218561

BOLT;SOCKET M14X2.0X45

SERIAL: 1001-1170

4шт.

45

S2218566

BOLT;SOCKET M14X2.0X45

SERIAL: 1171

4шт.

52

S5102703

WASHER;SPRING M12

desc: RONDELLE ELASTIQUE

5шт.

56

2114-1058D30

WASHER

desc: RONDELLE

7шт.

57

S4012733

NUT M12X1.75

desc: ECROU

1шт.

58

2195-3830

BRACKET

desc: SUPPORT

1шт.
