Запчасти Doosan Daewoo TRACK SPRING ASSY(2) TRACK PARTS

43

2270-1146

IDLER SUB ASS'Y

SERIAL: 216

2шт.

43B

2274-6014

TRACK SPRING ASS'Y

SERIAL: 216-295

1шт.

43B

2274-6014A

TRACK SPRING ASS'Y

SERIAL: 296

1шт.

43Ba

2193-6005

BODY

desc: . CARTER

1шт.

43Bb

2197-6011

BRACKET

desc: . SUPPORT

1шт.

43Bc

2444-6003

ROD ASS'Y

SERIAL: 216-295

1шт.

43Bc

2444-6003A

ROD ASS'Y

SERIAL: 296

1шт.

43Bd

2129-6010

SPRING

desc: . RESSORT

1шт.

43Be

2444-6004

TIE;BAR

desc: . TIGE

1шт.

43Bf

2121-6036

NUT

desc: . ECROU

1шт.

43Bg

-

ROD PACKING Ґх100XҐх120X12T

SC: D

1шт.

43Bh

-

RING;BACKUP UP Ґх100XҐх120X12T

SC: D

1шт.

43Bi

-

SEAL;DUST Ґх100XҐх120X12T

SC: D

1шт.

43Bj

2121-6035

NUT

desc: . ECROU

1шт.

43Bk

2621-6019

PLATE

desc: . PLAQUE

1шт.

43Bl

-

BOLT M14X1.5X35

desc: . BOULON A 6 PANS

1шт.

43Bm

-

WASHER;SPRING M14

desc: . RONDELLE ELASTIQUE

1шт.

43C

S0570061

BOLT M20X2.5X60

desc: . BOULON A 6 PANS

4шт.

43D

S5103103

WASHER;SPRING M20

desc: . RONDELLE ELASTIQUE

4шт.

38

S8180251

RING;SEAL

desc: BAGUE D'ETANCHEITE

1шт.

39

2181-4247

ADAPTER

desc: RACCORD ADAPTATEUR

1шт.

40

2420-1035A

VALVE ASS'Y

SERIAL: 1-305

1шт.

40

2420-1242

VALVE ASS'Y

SERIAL: 306

1шт.

*

2274-6014AKT

SEAL KIT;TRACK SPRING

SC: S

1шт.
