Запчасти Doosan Daewoo TRACK SHOE ASSY-900G OPTION PARTS

-

2272-9042D4

TRACK SHOE ASS'Y-900G

SERIAL: 69-250

2шт.

1

2272-6161

TRACK LINK ASS'Y

desc: ENSEMBLE MAILLON DE CHAINES

2шт.

1A

2272-6144

LINK(R.H)

desc: . RACCORD ADAPTATEUR

49шт.

1B

2272-6145

LINK(L.H)

desc: . RACCORD ADAPTATEUR

49шт.

1C

2272-6135

LINK;MASTER(R.H)

desc: . ADAPTATEUR

1шт.

1D

2272-6136

LINK;MASTER(L.H)

desc: . ADAPTATEUR

1шт.

1E

2123-6079A

PIN

desc: . BROCHE

49шт.

1F

2123-6080

PIN;MASTER

desc: . BROCHE PRINCIPALE

1шт.

1G

2110-6065B

BUSHING

desc: . DOUILLE

49шт.

1H

2110-6066A

BUSHING;MASTER

desc: . DOUILLE PRINCIPALE

1шт.

1I

2271-6018

COLLAR

desc: . BRIDE

2шт.

1J

2123-6081

PIN;SMALL

desc: . BROCHE

1шт.

1K

2180-6077A

SEAL;DUST

desc: . JOINT

98шт.

1L

2120-6025

BOLT;TRACK

desc: . BOULON A 6 PANS

200шт.

1M

2121-6027

NUT;TRACK

desc: . ECROU

200шт.

1N

2273-6054D5

SHOE;TRACK-900§® 13t

desc: . PATIN

50шт.

1N

2273-6058D5

SHOE;TRACK-900§® 16t

desc: . PATIN

50шт.

2

2195-3695D1

BRACKET

SERIAL: 246

2шт.
