Запчасти Doosan Daewoo INJECTION PIPE ENGINE PARTS

|$1

65.10301-6035

INJECTION PIPE KIT(1-1. 4-1)

desc: CONDUITES D'INJECTION

1шт.

1-1

65.10301-6153

INJECTION PIPE ASS'Y

desc: ENSEMBLE CONDUITES D'INJECTION

1шт.

1

65.10301-5173

PIPE;INJECTION NO.1

SC: D

1шт.

2

65.10301-5174

PIPE;INJECTION NO.2

SC: D

1шт.

3

65.10301-5175

PIPE;INJECTION NO.3

SC: D

1шт.

4-1

65.10301-6154

INJECTION PIPE ASS'Y

desc: ENSEMBLE CONDUITES D'INJECTION

-1шт.

4

65.10301-5176

PIPE;INJECTION NO.4

SC: D

1шт.

5

65.10301-5177

PIPE;INJECTION NO.5

SC: D

1шт.

6

65.10301-5178

PIPE;INJECTION NO.6

SC: D

1шт.

13

65.96330-0134

TUBE;FUEL OVER FLOW

desc: TUBE

1шт.

14

65.97445-0001

CLAMP;SPRING

desc: COLLIER A RESSSORT

2шт.

15

65.12301-5096

FUEL OVER FLOW PIPE ASS'Y

desc: ENSEMBLE CONDUITES DE TROP-PLEIN

1шт.

16

65.98150-0042

SCREW;HOLLOW M8X1

desc: VIS CREUSE

6шт.

17

06.56180-0712

RING;SEAL A8X14

desc: BAGUE D'ETANCHEITE

12шт.

18

65.97401-6002

3 PIPE CLIP ASS'Y

desc: ENSEMBLE CLIP 3 TUBES

4шт.

19

65.97401-6001

2 PIPE CLIP ASS'Y

desc: ENSEMBLE CLIP 2 TUBES

2шт.
