Запчасти Doosan Daewoo CYLINDER HEAD ENGINE PARTS

|$1

65.03101-6496

CYLINDER HEAD ASS'Y(FRONT)

SERIAL: 400007

1шт.

|$2

65.03101-6496V

CYLINDER HEAD ASS'Y(FRONT)

SERIAL: 400008

1шт.

1

65.03101-0296

HEAD;CYLINDER(FRONT)

desc: CULASSE

1шт.

1

65.03101-0296U

HEAD;CYLINDER(FRONT)

desc: CULASSE

1шт.

1

06.15091-0322

PLUG;CORE Ґх32

desc: BOUCHON

2шт.

1

65.90302-0042

PLUG;CORE Ґх32

desc: BOUCHON

2шт.

1

06.15091-0319

PLUG;CORE Ґх28

desc: BOUCHON

5шт.

1

65.90302-0041

PLUG;CORE Ґх28

desc: BOUCHON

6шт.

1

06.15091-0317

PLUG;CORE Ґх25

desc: BOUCHON

3шт.

1

65.90302-0048

PLUG;CORE Ґх25

desc: BOUCHON

3шт.

1

06.15091-0315

PLUG;CORE Ґх22

desc: BOUCHON

2шт.

1

65.90302-0049

PLUG;CORE Ґх22

desc: BOUCHON

3шт.

2

65.91001-0013

PLUG

desc: BOUCHON

2шт.

3

65.03201-1008

GUIDE;VALVE

desc: GUIDE-SOUPAPE

12шт.

3

65.03203-1031

RING;VALVE SEAT(EXHAUST)

desc: BAGUE DE SIEGE DE SOUPAPE(ECHAPPEMENT)

6шт.

3

65.03203-1042

RING;VALVE SEAT(EXHAUST)

desc: BAGUE DE SIEGE DE SOUPAPE(ECHAPPEMENT)

6шт.

3

65.03203-1036

RING;VALVE SEAT(INTAKE)

desc: BAGUE DE SIEGE DE SOUPAPE(ADMISSION)

6шт.

3

65.03203-1041

RING;VALVE SEAT(INTAKE)

desc: BAGUE DE SIEGE DE SOUPAPE(ADMISSION)

6шт.

4

65.03101-6497

CYLINDER HEAD ASS'Y(REAR)

SERIAL: 400007

1шт.

4

65.03101-6497V

CYLINDER HEAD ASS'Y(REAR)

SERIAL: 400008

1шт.

4

65.03101-0297

HEAD;CYLINDER(REAR)

desc: CULASSE

1шт.

4

65.03101-0297U

HEAD;CYLINDER(REAR)

desc: CULASSE

1шт.

4

06.15091-0322

PLUG;CORE Ґх32

desc: BOUCHON

2шт.

4

65.90302-0042

PLUG;CORE Ґх32

desc: BOUCHON

2шт.

4

06.15091-0319

PLUG;CORE Ґх28

desc: BOUCHON

7шт.

4

65.90302-0041

PLUG;CORE Ґх28

desc: BOUCHON

6шт.

4

06.15091-0317

PLUG;CORE Ґх25

desc: BOUCHON

3шт.

4

65.90302-0048

PLUG;CORE Ґх25

desc: BOUCHON

3шт.

4

06.15091-0315

PLUG;CORE Ґх22

desc: BOUCHON

1шт.

4

65.90302-0049

PLUG;CORE Ґх22

desc: BOUCHON

3шт.

5

65.90020-0034

BOLT;CYLINDER HEAD

desc: BOULON DE CULASSE

28шт.

6-1

65.03901-0049

GASKET;CYLINDER HEAD(FRONT)

SERIAL: 400007

1шт.

6-1

65.03901-0051

GASKET;CYLINDER HEAD(FRONT)

SERIAL: 400008

1шт.

6-2

65.03901-0050

GASKET;CYLINDER HEAD(REAR)

SERIAL: 400007

1шт.

6-2

65.03901-0052

GASKET;CYLINDER HEAD(REAR)

SERIAL: 400008

1шт.

7

65.41520-0002

BRACKET;HANGER(FRONT)

desc: SUPPORT

1шт.

8

06.01494-4408

BOLT;HEX. M14X1.5X45

desc: BOULON A 6 PANS

1шт.

9

06.16731-2110

WASHER;SPRING A14

desc: RONDELLE ELASTIQUE A14

2шт.

10

06.01734-4411

BOLT;HEX. M14X1.5X30

desc: BOULON A 6 PANS

1шт.

12

06.01913-3215

BOLT;HEX. M10X1.5X25

desc: BOULON A 6 PANS

1шт.

13

65.91701-0275

SPACER

desc: BAGUE D'ECARTEMENT

1шт.

14

65.03905-0014

GASKET;CYLINDER HAED COVER

SERIAL: 400007

1шт.

14

65.03905-0018

GASKET;CYLINDER HAED COVER

SERIAL: 400008

1шт.

-

65.03401-6020

CYLINDER HEAD COVER ASS'Y

desc: COUVERCLE DE CULASSE

1шт.

15

65.03401-0033

COVER;CYLINDER HEAD

desc: . COUVERCLE DE CULASSE

1шт.

16

65.92911-5001

CHAIN ASS'Y

desc: . ENSEMBLE CHAINE

1шт.

17

65.01810-0001

CAP;OIL FILLER

desc: . VIBREUR

1шт.

18

65.03905-0009

PACKING

SERIAL: 400007

6шт.

18

65.03905-0017

PACKING

SERIAL: 400008

6шт.

19

65.90701-0052

WASHER

desc: RONDELLE

6шт.

20

65.90020-0012

BOLT;HEX

desc: BOULON A 6 PANS

6шт.

21

65.97871-0252

PLATE;NAME

desc: PLAQUE D'IDENTIFICATION

1шт.

22

65.97801-0036

PLATE;CAUTION

desc: PLAQUE D'AVERTISSEMENT

1шт.
