Запчасти Doosan Daewoo HEATER BOX BODY PARTS

|$1

2920-1040G

HEATER BOX

desc: CHAUFFAGE

1шт.

|$2

2920-1040H

HEATER BOX

ICA: I

1шт.

|$3

2920-1040J

HEATER BOX

SERIAL: 39-93

1шт.

1

2195-3715E

SUPPORT

desc: SUPPORT

1шт.

1

2195-3715G

SUPPORT

desc: SUPPORT

1шт.

2

2621-2643B

COVER

SERIAL: 0001-0018

1шт.

2

2621-2643E

COVER

SERIAL: 0019

1шт.

3

2621-2644B

COVER

desc: COUVERCLE

1шт.

4

2621-2693C

COVER

desc: COUVERCLE

1шт.

5

2191-3235A

PLATE

desc: PLAQUE

2шт.

6

2415-9003

NOZZLE;AIRCON

desc: BUSE

4шт.

7

S0504453

BOLT M6X1.0X12

desc: BOULON A 6 PANS

12шт.

8

S5000313

WASHER;PLAIN M6

desc: RONDELLE PLATE

12шт.

9

S0508652

BOLT M8X1.25X16

ICA: Y

9шт.

9

S0508653

BOLT M8X1.25X16

desc: BOULON A 6 PANS

9шт.

10

S5010511

WASHER;PLAIN M8

ICA: Y

9шт.

10

S5010513

WASHER;PLAIN M8

desc: RONDELLE PLATE

9шт.

11

2920-1040-11

RUBBER;CUSHION

SERIAL: 39

1шт.

14

2190-2049

PLATE;NAME

desc: PLAQUE D'IDENTIFICATION

1шт.

15

2621-2774A

COVER

SERIAL: 0001-0018

1шт.

15

2621-2920

COVER

SERIAL: 0019

1шт.

16

2621-2642A

COVER

SERIAL: 1-93

1шт.

17

S0504453

BOLT M6X1.0X12

desc: BOULON A 6 PANS

4шт.

18

S5110301

WASHER;SPRING M6

ICA: Y

4шт.

18

S5110303

WASHER;SPRING M6

desc: RONDELLE ELASTIQUE

4шт.

19

S5020311

WASHER;PLAIN M6

ICA: Y

4шт.

19

S5020313

WASHER;PLAIN M6

desc: RONDELLE PLATE

4шт.

20

2158-1017D1

HOSE Ґх54

desc: TUYAU FLEXIBLE

4шт.

21

S8450044

CLAMP;HOSE

desc: COLLIER

8шт.

22

S0511852

BOLT M10X1.5X20

ICA: Y

4шт.

22

S0511853

BOLT M10X1.5X20

desc: BOULON A 6 PANS

4шт.

23

S5102601

WASHER;SPRING M10

ICA: Y

4шт.

23

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE M10

4шт.

23

S5102603

WASHER;SPRING M10

SERIAL: 94

8шт.

24

S5010611

WASHER;PLAIN M10

ICA: Y

4шт.

24

S5010613

WASHER;PLAIN M10

desc: RONDELLE PLATE M10

4шт.

24

S5010613

WASHER;PLAIN M10

SERIAL: 94

8шт.

25

S3644193

SCREW;TAPPING M3X10

desc: VIS

2шт.

26

2415-9005

NOZZLE;SPINDLE

desc: BUSE

1шт.

27

2125-1081

CASE;UPPER

desc: CARTER

1шт.

28

2125-1082

CASE;LOWER

desc: CARTER

1шт.

29

S3640523

SCREW;TAPPING M5X10

desc: VIS

4шт.

30

2161-1953

PLATE

desc: PLAQUE

1шт.

31

2124-1084D3

CLIP;BAND L250

desc: ATTACHE

1шт.

32

2161-1744

RUBBER;DF

desc: CAOUTCHOUC

1шт.

33

2160-1219

GROMMET

desc: ETOUPE

1шт.

34

2161-1744

RUBBER;DF

desc: CAOUTCHOUC

1шт.

35

2161-1744

RUBBER;DF

desc: CAOUTCHOUC

1шт.

36

2920-1040-36

RUBBER;CUSHION

SERIAL: 39

1шт.

37

2621-3023

COVER

SERIAL: 0039

1шт.
