Запчасти Doosan Daewoo MAIN PIPING-ONE & TWO WAY OPTION PARTS

-

400-00934

MAIN PIPING-ONE & TWO WAY

SC: D

-2шт.

1

140-01176

PIPE

desc: TUYAU

1шт.

2

140-01177

PIPE

desc: TUYAU

1шт.

3

DS2016010

HOSE-1450L

desc: TUYAU FLEXIBLE

2шт.

4

DS2039070

HOSE-970L

desc: TUYAU FLEXIBLE

1шт.

5

DS2040318

HOSE-750L

desc: TUYAU FLEXIBLE

1шт.

6

DS2043064

HOSE-1150L

desc: TUYAU FLEXIBLE

1шт.

7

DS2017034

HOSE-1200L

desc: TUYAU FLEXIBLE

1шт.

8

421-00019

VALVE;SWITCH

desc: VANNE

1шт.

9

423-00150

BLOCK

desc: BLOC

1шт.

10

195-01938

BRACKET

desc: SUPPORT

2шт.

12

195-01943

BRACKET

desc: SUPPORT

1шт.

13

124-00249A

CLAMP;PIPE

desc: ATTACHE DE TUBE

1шт.

14

2124-1696

CLAMP;PIPE

desc: ATTACHE DE TUBE

2шт.

15

2124-1026D3

CLAMP;PIPE

desc: ATTACHE DE TUBE

1шт.

16

2161-2251A

RUBBER

desc: CAOUTCHOUC

4шт.

17

2181-9078

FLANGE;SPLIT

desc: BRIDE

18шт.

18

S2212266

BOLT;SOCKET M10X1.5X30

desc: BOULON A 6 PANS CREUX

36шт.

19

S2212466

BOLT;SOCKET M10X1.5X40

desc: BOULON A 6 PANS CREUX

8шт.

20

S0512253

BOLT M10X1.5X30

desc: BOULON A 6 PANS

8шт.

21

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

8шт.

22

S0560953

BOLT M12X1.75X60

desc: BOULON A 6 PANS

4шт.

23

S0561053

BOLT M12X1.75X65

desc: BOULON A 6 PANS

1шт.

24

2120-2196D11

BOLT;SET M12X1.75X35

desc: BOULON A 6 PANS

2шт.

25

S5102703

WASHER;SPRING M12

desc: RONDELLE ELASTIQUE

5шт.

26

2180-1026D19

O-RING

desc: JOINT TORIQUE

11шт.

27

S8030161

O-RING

desc: JOINT TORIQUE

3шт.

28

S8000291

O-RING

desc: JOINT TORIQUE

1шт.

29

2181-4133D6

ADAPTER

desc: ADAPTEUR

1шт.
