Запчасти Doosan Daewoo COOLING FAN ENGINE PARTS

1

65.06650-6016

FAN DRIVE ASS'Y

desc: SUPPORT

1шт.

2

65.06651-0005

HOUSING;FAN DRIVE

SC: D

1шт.

3

65.93410-0024

BEARING;UNIT

desc: . PALIER

1шт.

4

06.29020-0132

RING;SNAP

desc: . CIRCLIP

1шт.

5

65.06504-0013

HUB;FAN DRIVE

desc: . MOYEU DE FIXATION

1шт.

6

65.06606-0057

PULLEY;FAN

desc: POULIE

1шт.

7

06.01943-3332

BOLT ASS'Y M12X1.5X110

desc: BOULON A 6 PANS

2шт.

8

65.19103-5035

BRACKET

desc: SUPPORT

1шт.

9

06.01013-9226

BOLT;HEX M10X1.5X110

desc: BOULON A 6 PANS

2шт.

10

06.16731-2108

WASHER;SPRING

desc: RONDELLE ELASTIQUE

2шт.

11

65.06611-0125

FLANGE;FAN

SERIAL: 030227

1шт.

11

65.06611-0125A

FLANGE;FAN

SERIAL: 030228

1шт.

12

65.06601-5067

FAN;COOLING

desc: VENTILATEUR

1шт.

13

06.01013-9142

BOLT;HEX M8X135

desc: BOULON A 6 PANS

6шт.

14

06.16731-2107

WASHER;SPRING

desc: RONDELLE ELASTIQUE

6шт.

15

65.96801-0130

V-BELT

SERIAL: 040205

1шт.

15

65.96801-0130A

V-BELT

SERIAL: 040206

1шт.
