Запчасти Doosan Daewoo RADIATOR BODY PARTS

-

201-00088

ENGINE ASS'Y

SC: D

-2шт.

2

202-00077B

RADIATOR ASS'Y

SERIAL: 1001-1254

1шт.

2

202-00077C

RADIATOR ASS'Y

SERIAL: 1255-1514

1шт.

2

202-00077E

RADIATOR ASS'Y

SERIAL: 1515

1шт.

2A

13F91000

RADIATOR ASS'Y

desc: . RADIATEUR

1шт.

2B

13F52000

OIL COOLER ASS'Y

SERIAL: 1001-1514

1шт.

2B

13F52000A

OIL COOLER ASS'Y

SERIAL: 1515

1шт.

2C

13F53000

CAC ASS'Y

desc: . REFRIGERATION

1шт.

2D

13F54000

FRAME ASS'Y

desc: . BATI

1шт.

2E

13F55000

SHROUD ASS'Y

desc: . ARITER

1шт.

2F

13F56000

FAN GUARD ASS'Y

desc: . ABRITER

2шт.

2G

13F57000

WIRE NET ASS'Y

desc: . CABLE

2шт.

2H

13F58000

TOP PLATE

desc: . PLAQUE

1шт.

2I

P06A

CAP ASS'Y

desc: . BOUCHON

1шт.

2J

P04

DRAIN COCK ASS'Y

desc: . ROBINET

1шт.

2K

P03

DRAIN HOSE

desc: . TUYAU FLEXIBLE

1шт.

2L

P1106

BOLT;WING M6X1.0X15

desc: . BOULON A 6PANS

6шт.

2M

P1306

WASHER;PLAIN

desc: . RONDELLE

6шт.

2N

P1406

WASHER;SPRING

desc: . RONDELLE ELASTIQUE

6шт.

2O

P1108

BOLT M81.25X20

desc: . BOULON A 6 PANS

8шт.

2P

P1110

BOLT M10X1.25X25

desc: . BOULON A 6 PANS

24шт.

2Q

P1110

BOLT M12X1.75X30

desc: . BOULON A 6 PANS

4шт.

2R

P1210

WASHER;PLAIN

desc: . RONDELLE PLATE

4шт.

2S

P1210

WASHER;SPRING

desc: . RONDELLE ELASTIQUE

4шт.
