Запчасти Doosan Daewoo CRANK SHAFT ASSY ENGINE PARTS

1

65.02101-7541A

CRANK SHAFT ASS'Y

SERIAL: 020830

1шт.

1

65.02101-7541B

CRANK SHAFT ASS'Y

SERIAL: 020831

1шт.

2

65.02101-7054A

CRANK SHAFT ASS'Y(3~7)

SERIAL: 020830

1шт.

2

65.02101-7054B

CRANK SHAFT ASS'Y(3~7)

SERIAL: 020831

1шт.

3

65.02101-0054

SHAFT;CRANK

SERIAL: 020830

1шт.

3

65.02101-0054A

SHAFT;CRANK

SERIAL: 020831

1шт.

4

65.02110-0014

WEIGHT;BALANCE

SERIAL: 020830

4шт.

4

65.02110-0014E

WEIGHT;BALANCE

SERIAL: 020831

4шт.

5

65.02110-0013

WEIGHT;BALANCE

SERIAL: 020830

4шт.

5

65.02110-0013E

WEIGHT;BALANCE

SERIAL: 020831

4шт.

6

65.90430-0012B

BOLT;CRANK SHAFT

desc: .. BOULON A 6 PANS

8шт.

7

65.90430-0013B

BOLT;CRANK SHAFT

desc: .. BOULON A 6 PANS

8шт.

8

65.02101-0057

CRANK SHAFT ASS'Y

SERIAL: 020830

1шт.

8

65.02101-0057A

CRANK SHAFT ASS'Y

SERIAL: 020831

1шт.

9

65.02101-0060

CRANK SHAFT ASS'Y

SERIAL: 020830

1шт.

9

65.02101-0060A

CRANK SHAFT ASS'Y

SERIAL: 020831

1шт.

10

65.02115-0008B

GEAR;CRANK SHAFT

desc: PIGNON

1шт.

11

06.22022-0912

PIN;DOWEL

desc: GOUPILLE D'AJUSTAGE

1шт.

12

65.01110-6055A

METAL;MAIN STD

desc: COUSSINET COTE STD

7шт.

12

65.01110-6068A

METAL;MAIN 0.25

SC: US

7шт.

12

65.01110-6069A

METAL;MAIN 0.50

SC: US

7шт.

12

65.01110-6070A

METAL;MAIN 0.75

SC: US

7шт.

13

65.01150-0017A

WASHER;THRUST(UPR.) STD

desc: RONDELLE DE BUTEE(HAUT) STD

2шт.

13

65.01150-0048A

WASHER;THRUST(UPR.) 0.25

SC: OS

2шт.

13

65.01150-0049A

WASHER;THRUST(UPR.) 0.50

SC: OS

2шт.

14

65.01150-0018B

WASHER;THRUST(LOW.) STD

desc: RONDELLE DE BUTEE(BAS) STD

2шт.

14

65.01150-0052B

WASHER;THRUST(LOW.) 0.25

SC: OS

2шт.

14

65.01150-0053B

WASHER;THRUST(LOW.) 0.50

SC: OS

2шт.

15

65.02201-7032

DAMPER;VIBRATION

desc: VOLANT

1шт.

16

06.01913-3215

BOLT ASS'Y M10X25

SERIAL: 040701

6шт.

16

65.90020-0062B

BOLT ASS'Y M10X20

SERIAL: 040702

6шт.

17

65.02601-0180

PULLEY;V-BELT

desc: POULLIE

1шт.

18

65.90720-0022

WASHER

SERIAL: 010601

1шт.

18

REP_PNO: 06.02106-0622

-1шт.

18

65.90701-0088

WASHER

SERIAL: 010602

1шт.

19

06.02106-0623

BOLT;SOCKET M12X1.5X70

desc: BOULON A 6 PANS CREUX

8шт.

19

06.02106-0622

BOLT;SOCKET M12X1.5X65

desc: BOULON A 6 PANS CREUX

8шт.

20

65.02301-5103

FLYWHEEL ASS'Y

desc: VOLANT

1шт.

21

65.02301-0249

FLYWHEEL

desc: . VOLANT

1шт.

22

65.02310-0011B

GEAR;STARTER RING

desc: . COURONNE DENTEE

1шт.

23

06.16731-2110

WASHER;SPRING

desc: RONDELLE ELASTIQUE

8шт.

24

65.90001-0084

BOLT;HEX

desc: BOULON A 6 PANS

8шт.

25

06.22022-1010

PIN;DOWEL

desc: GOUPILLE D'AJUSTAGE

1шт.
