Запчасти Doosan Daewoo TIMING GEAR CASE ENGINE PARTS

1

65.01304-0021A

CASE;TIMING GEAR

SERIAL: 000703

1шт.

1

65.01304-0023C

CASE;TIMING GEAR

SERIAL: 000704

1шт.

3

65.01903-0048

GASKET

SERIAL: 011026

1шт.

3

65.01903-0048B

GASKET

SERIAL: 011027

1шт.

4

65.91010-0017

PIN;DOWEL

desc: GOUPILLE D'AJUSTAGE

2шт.

7

06.01943-3317

BOLT ASS'Y M12X1.5X30

desc: BOULON A 6 PANS

3шт.

8

06.01943-3320

BOLT ASS'Y M12X1.5X45

desc: BOULON A 6 PANS

5шт.

9

06.01913-3215

BOLT ASS'Y M12X25

desc: BOULON A 6 PANS

1шт.

10

65.01903-0050

GASKET

desc: JOINT

1шт.

11

65.01305-5049F

COVER;TIMING GEAR CASE

SERIAL: 011022

1шт.

11

65.01305-5049G

COVER;TIMING GEAR CASE

SERIAL: 011023

1шт.

14

06.01923-2917

BOLT ASS'Y M6X30

desc: BOULON A 6 PANS

7шт.

15

06.01923-2914

BOLT ASS'Y M6X22

desc: BOULON A 6 PANS

6шт.

16

06.01953-3326

BOLT ASS'Y M12X1.5X75

desc: BOULON A 6 PANS

5шт.

18

65.01510-0157

SEAL;OIL

desc: JOINT D'HUILE

1шт.

19

65.91601-0003

COVER ASS'Y

SERIAL: 040325

1шт.

19

65.91601-6003A

COVER ASS'Y

SERIAL: 040326

1шт.

20

65.54901-0025A

GASKET(FOR A/C)

desc: JOINT

1шт.

21

06.01913-3217

BOLT ASS'Y M10X30

desc: BOULON A 6 PANS

4шт.

22

60.91601-0010

COVER

desc: COUVERCLE

1шт.

23

65.47901-0010

GASKET;P/S PUMP

desc: JOINT

1шт.

24

06.01913-3219

BOLT M10X40

desc: BOULON A 6 PANS

2шт.

25

06.01013-9221

BOLT;HEX. M10X80

desc: BOULON A 6 PANS

1шт.

26

06.16731-2108

WASHER;SPRING

desc: RONDELLE

1шт.

27

65.98150-0033

SCREW;HOLLOW

desc: VIS CREUSE

1шт.

28

06.56180-0712

RING;SEAL

desc: BAGUE D'ETANCHEITE

2шт.

29

65.05701-5361

OIL PIPE ASS'Y

desc: CONDUITE

1шт.

30

06.01913-2910

BOLT;HEX. M6X12

desc: BOULON A 6 PANS

1шт.

31

06.11063-8212

NUT;HEX. M6

desc: ECROU 6 PANS

1шт.
