1
65.04401-0010K
SHAFT;CAM
SERIAL: 040827
1шт.
1
65.04401-0010L
SHAFT;CAM
SERIAL: 040828
1шт.
2
65.98112-0038
FLANGE
desc: BRIDE
1шт.
3
65.90001-6003
BOLT ASS'Y M6X14
desc: BOULON A 6 PANS
2шт.
4
65.04501-0007A
GEAR;CAM SHAFT
desc: PIGNON
1шт.
5
06.22022-1014
PIN;DOWEL
desc: GOUPILLE D'AJUSTAGE
1шт.
6
06.01913-3119
BOLT ASS'Y M8X40
desc: BOULON A 6 PANS
4шт.
7
65.04505-5015
IDLE GEAR ASS'Y(8~9)
SERIAL: 001204
1шт.
7
65.04505-5016
IDLE GEAR ASS'Y(8~9)
SERIAL: 001205
1шт.
8
65.04505-0009
GEAR;IDLE
SERIAL: 001204
1шт.
8
65.04505-0033
GEAR;IDLE
SERIAL: 001205
1шт.
9
65.04507-0003
BUSH;IDLE GEAR
SERIAL: 001204
1шт.
9
65.04507-0004
BUSH;IDLE GEAR
SERIAL: 001205
1шт.
10
65.04506-0007
PIN;IDLE GEAR
SERIAL: 001204
1шт.
10
65.04506-0033
PIN;IDLE GEAR
SERIAL: 001205
1шт.
12
65.90720-0018
WASHER;THRUST
desc: RONDELLE DE BUTEE
1шт.
14
06.01914-3225
BOLT ASS'Y M10X70
SERIAL: 001204
2шт.
14
06.01015-7220
BOLT;HEX M10X1.5X75
SERIAL: 020118
2шт.
14
06.01015-9220
BOLT;HEX M10X1.5X75
SERIAL: 020119
2шт.
15
06.16731-2108
WASHER;SPRING
SERIAL: 001205
2шт.
16
65.04101-0044
VALVE;EXHAUST
desc: VANNE
6шт.
17
65.04101-0043
VALVE;INTAKE
desc: SOUPAPE D'ADMISSION
6шт.
18
65.04102-6004
VALVE SPRING ASS'Y(17~18)
SERIAL: 030122
6шт.
18
65.04102-6004A
VALVE SPRING ASS'Y(17~18)
SERIAL: 030123
6шт.
19
65.04102-0002
SPRING;VALVE(INNER)
SERIAL: 030122
1шт.
19
65.04102-0002A
SPRING;VALVE(INNER)
SERIAL: 030123
1шт.
20
65.04102-0066
SPRING;VALVE(OUTER)
desc: . RESSORT DE EXTERIEUR SOUPAPE
6шт.
21
65.04102-0066
SPRING;VALVE INTAKE
desc: RESSORT DE EXTERIEUR SOUPAPE
6шт.
22
65.04103-0014
RETAINER;VALVE SPRING
desc: COUPELLE DE RESSORT DE SOUPAPE
12шт.
23
65.04104-0007
COTTER;VALVE
desc: CLAVETTE DE SOUPAPE
24шт.
24
65.04902-0010
SEAL;VALVE STEM
desc: JOINT DE QUEUE DE SOUPAPE
12шт.
25
65.04103-0011
SEAT;VALVE SPRING
SERIAL: 001204
12шт.
25
65.04103-0078
SEAT;VALVE SPRING
SERIAL: 001205
12шт.
26
65.04200-6027A
ROCKER ARM & SHAFT ASS'Y(27~33)
SERIAL: 001104
2шт.
26
65.04200-6027C
ROCKER ARM & SHAFT ASS'Y(27~33)
SERIAL: 001105
2шт.
27
65.04203-5010
ROCKER ARM SHAFT ASS'Y
desc: . AXE DE CULBUTEUR
1шт.
28
65.97601-0104
SPRING;ROCKER ARM SHAFT
desc: . RESSORT
2шт.
29
65.04201-5014D
ROCKER ARM ASS'Y
SERIAL: 001104
6шт.
29
65.04201-5014E
ROCKER ARM ASS'Y
SERIAL: 001105
6шт.
32
65.04205-0003
BOLT;ADJUSTING M10X1.0
desc: . VIS DE REGLAGE
6шт.
33
65.90501-0003
NUT;HEX. M10X1.0
desc: . ECROU 6 PANS
6шт.
34
65.04202-0014A
BRACKET;ROCKER ARM SHAFT
desc: . SUPPORT
3шт.
35
06.16731-2108
WASHER;SPRING
desc: . RONDELLE
6шт.
36
06.01013-9221
BOLT;HEX. M10X80
desc: . BOULON 6 PANS CREUX
6шт.
37
65.97601-0053
SPRING;CONICAL
desc: . RESSORT
2шт.
38
65.90710-0039
WASHER;ROCKER ARM
desc: . RONDELLE D'AXE DE CULBUTEURS
2шт.
39
06.29010-0120
RING;SNAP
desc: . CIRCLIP
2шт.
40
06.15010-2311
WASHER;PLAIN 8.4
desc: . RONDELLE
3шт.
41
06.01283-7112
BOLT;HEX. M8X18
desc: . BOULON A 6 PANS
3шт.
42
65.04301-0006
TAPPET;VALVE
desc: POUSSOIR DE TIGE DE CULBUTEUR
12шт.
43
65.04302-5011
ROD;PUSH
desc: TIGE DE POUSSOIR
12шт.
