Запчасти Doosan Daewoo MAIN PIPING(2)-BOOM BODY PARTS

-

2400-1997

MAIN PIPING

SC: D

-2шт.

2

S0515353

BOLT M12X1.75X35

desc: BOULON A 6 PANS

4шт.

3

S5102703

WASHER;SPRING M12

desc: RONDELLE ELASTIQUE

6шт.

4

2140-1449A

PIPE;BOOM UP

desc: TUYAU

1шт.

5

2140-1450A

PIPE;BOOM DOWN

SERIAL: 1001-1160

1шт.

5

2140-1450B

PIPE;BOOM DOWN

SERIAL: 1161

1шт.

6

2180-1026D19

O-RING

desc: JOINT TORIQUE

10шт.

7

S2212361

BOLT;SOCKET M10X1.5X35

SERIAL: 1001-1370

4шт.

7

S2212366

BOLT;SOCKET M10X1.5X35

SERIAL: 1371

4шт.

9

2124-1025D5

CLAMP;PIPE

desc: ATTACHE DE TUBE

2шт.

10

S0561053

BOLT M12X1.75X65

desc: BOULON A 6 PANS

2шт.

11

2891-1493A

PLATE

desc: PLAQUE

2шт.

12

2114-1058D30

WASHER

desc: RONDELLE

4шт.

24

2184-1081D124

HOSE PF1-1180L

desc: TUYAU FLEXIBLE

4шт.

26

S2212261

BOLT;SOCKET M10X1.5X30

SERIAL: 1001-1370

32шт.

26

S2212266

BOLT;SOCKET M10X1.5X30

SERIAL: 1371

32шт.

33

2181-9078

FLANGE;SPLIT

desc: FLASQUE EN DEUX PARTIES

16шт.

45

S2212761

BOLT;SOCKET M10X1.5X55

SERIAL: 1001-1370

4шт.

45

S2212766

BOLT;SOCKET M10X1.5X55

SERIAL: 1371

4шт.
