Запчасти Doosan Daewoo FUEL FILTER ENGINE PARTS

A

65.12501-7003

FUEL FILTER ASS'Y

desc: ENSEMBLE FILTRE A GAZOLE

1шт.

1

65.12540-5019

BRACKET;FUEL FILTER

desc: SUPPORT

1шт.

2

06.01733-4311

BOLT;HEX. M12X1.5X30

desc: BOULON A 6 PANS

2шт.

3

06.01953-3320

BOLT;HEX. M12X1.5X45

desc: BOULON A 6 PANS

2шт.

4

06.15010-2313

WASHER;PLAIN A12.5

desc: RONDELLE PLATE

2шт.

5

06.16731-2109

WASHER;SPRING A12

desc: RONDELLE ELASTIQUE

2шт.

6

65.12504-5002

COVER;FUEL FILTER

SC: D

1шт.

7

65.96507-0003

RING;SEAL

SC: D

2шт.

8

65.12509-5002

SCREW;BREATHER M8

SC: D

2шт.

9

06.56180-0811

RING;SEAL A8X12

SC: D

2шт.

10

06.01013-7122

BOLT;HEX. M8X75

SC: D

2шт.

11

65.12506-0006

PACKING

SC: D

2шт.

12

65.12503-5002

ELEMENT;FUEL FILTER (1ST)

desc: . ELEMENT FILTRE

1шт.

13

65.12503-5004

ELEMENT;FUEL FILTER (2ND)

desc: . ELEMENT FILTRANT

1шт.

14

65.12502-5002

HOUSING;FILTER

SC: D

2шт.

15

65.96341-0098

HOSE;FUEL(FILTER IN)

desc: TUYAU FLEXIBLE

1шт.

16

65.96340-0104

HOSE;FUEL(FILTER OUT)

desc: TUYAU FLEXIBLE

1шт.

17

65.90420-0004

SCREW;HOLLOW

desc: VIS CREUSE

2шт.

18

06.56190-0706

RING;SEAL A14X20

desc: BAGUE D'ETANCHEITE

4шт.

19

65.97460-0001

BAND;TENSION

desc: ATTACHE DE TUYAU

1шт.
