Запчасти Doosan Daewoo CRANK SHAFT ASSY ENGINE PARTS

-

65.02101-7054A

CRANK SHAFT ASS'Y

desc: ENSEMBLE VILEBREQUIN

1шт.

1

65.02101-0054

CRANK SHAFT

desc: VILEBREQUIN

1шт.

2

65.02111-0014

WEIGHT;BALANCE

desc: MASSE D'EQUILIBRAGE

4шт.

3

65.02110-0013

WEIGHT;BALANCE

desc: MASSE D'EQUILIBRAGE

4шт.

4

65.90430-0012A

BOLT;CRANK SHAFT

desc: BOULON DE PALIER DE VILEBREQUIN

8шт.

5

65.90430-0013A

BOLT;CRANK SHAFT

desc: BOULON DE PALIER DE VILEBREQUIN

8шт.

6

65.02115-0040

GEAR;CRANK SHAFT

desc: PIGNON DE VILEBREQUIN

1шт.

7

06.22022-0912

PIN;DOWEL 6M6X20

desc: BROCHE

1шт.

11

65.01110-6055

METAL;MAIN STD

desc: COUSSINET COTE STD

7шт.

11

65.11110-6068

METAL;MAIN 0.25

desc: COUSSINET 0.25

7шт.

11

65.01110-6069

METAL;MAIN 0.50

desc: COUSSINET 0.50

7шт.

11

65.01110-6070

METAL;MAIN 0.75

desc: COUSSINET 0.75

7шт.

11

65.01110-6071

METAL;MAIN 1.00

desc: COUSSINET 1.00

7шт.

12

65.01150-0017

WASHER;THRUST(UPPER) STD

desc: RONDELLE DE BUTEE(HAUT) STD

2шт.

12

65.01150-0027

WASHER;THRUST(UPPER) 0.25

desc: RONDELLE DE BUTEE(HAUT) 0.25

2шт.

12

65.01150-0028

WASHER;THRUST(UPPER) 0.50

desc: RONDELLE DE BUTEE(HAUT) 0.50

2шт.

13

65.01150-0018

WASHER;THRUST(LOWER) STD

desc: RONDELLE DE BUTEE(BAS) STD

2шт.

13

65.01150-0031

WASHER;THRUST(LOWER) 0.25

desc: RONDELLE DE BUTEE(BAS) 0.25

2шт.

13

65.01150-0032

WASHER;THRUST(LOWER) 0.50

desc: RONDELLE DE BUTEE(BAS) 0.50

2шт.

14

65.02201-7023

DAMPER;VIBRATION

ICA: I

1шт.

14

65.02201-7032

DAMPER;VIBRATION

SERIAL: 9800001

1шт.

15

06.01914-3215

BOLT;HEX. M10X25

desc: BOULON A 6 PANS

6шт.

17

65.02601-0149

PULLEY;V-BELT

SERIAL: 9600312

1шт.

17

65.02601-0157

PULLEY;V-BELT

SERIAL: 9600131

1шт.

18

65.90720-0022

WASHER

desc: RONDELLE

1шт.

19

06.02106-0622

BOLT;SOCKET M12X1.5X70

desc: BOULON 6 PANS CREUX

8шт.

20

65.02301-5015

FLY WHEEL

desc: VOLANT

1шт.

20-1

65.02301-0180A

FLY WHEEL ASS'Y

desc: VOLANT

1шт.

21

65.02310-0011B

GEAR;RING

desc: COURONNE DENTEE

1шт.

22

06.16731-2110

WASHER;SPRING A14

desc: RONDELLE ELASTIQUE A14

8шт.

23

65.90001-0084

BOLT;HEX. M14X1.5X40

desc: BOULON 6 PANS

8шт.

24

06.22220-1208

PIN;SPIRAL LOCK 8X16

desc: GOUPILLE DE BLOCAGE

1шт.
