Запчасти Doosan Daewoo PISTON ASSY ENGINE PARTS

1

65.02501-0032H

PISTON

desc: PISTON

6шт.

2

65.02503-0057

RING;TOP

desc: . SEGMENT COUP DE FEU

6шт.

3

65.02503-0097

RING;SECOND

desc: . SEGMENT DE COMPRESSION

6шт.

4

65.02503-0105

RING;OIL

desc: . BAGUE DE SOUTIEN

6шт.

5

65.02502-0050

PIN;PISTON

desc: AXE DE PISTON

6шт.

6

06.29020-0127

RING;SNAP 45X1.75

desc: CIRCLIP

12шт.

7

65.02401-6012

CONNECTION ROD ASS'Y

desc: BIELLE

6шт.

8

65.02401-0045

ROD;CONNECTING

desc: VIS DE BIELLE

6шт.

9

65.90020-0010D

BOLT;CONNECTING ROD

desc: VIS DE BIELLE

12шт.

10

65.91301-0010

PIN;DOWEL

desc: GOUPILLE D'AJUSTAGE 6m6x14

12шт.

11

65.02405-1001

BUSH;SMALL END

desc: COUSSINET. PIED DE BIELLE

6шт.

12

65.02410-6106

METAL;BIG END STD

desc: PALIER

6шт.

12

65.02410-6107

METAL;END STD 0.25

desc: PALIER

6шт.

12

65.02410-6108

METAL;BIG END 0.50

desc: PALIER

6шт.

12

65.02410-6109

METAL;BIG END 0.75

desc: PALIER

6шт.

12

65.02410-6110

METAL;BIG END 1.0

desc: PALIER

6шт.
