Запчасти Doosan Daewoo SUPPORT(3) BODY PARTS

-

2197-1145

SUPPORT ASS'Y

desc: ENSEMBLE SUPPORT

1шт.

2

2197-1149

SUPPORT

desc: SUPPORT

1шт.

5

2197-1147

SUPPORT

desc: SUPPORT

1шт.

6

2197-1150

SUPPORT

SERIAL: 1-3

1шт.

6

REP_PNO: 2621-3176A

-1шт.

6

2197-1150A

SUPPORT

SERIAL: 4

1шт.

7

2197-1151

SUPPORT

desc: SUPPORT

1шт.

9

2621-3174

COVER

SERIAL: 1-419

1шт.

9

2621-3174A

COVER

SERIAL: 420

1шт.

10

2621-3176

COVER

SERIAL: 1-3

1шт.

10

REP_PNO: 2197-1150A

-1шт.

10

2621-3176A

COVER

SERIAL: 4

1шт.

11

2621-3177

COVER

SERIAL: 1-3

1шт.

11

2621-3177A

COVER

SERIAL: 4-103

1шт.

11

2621-3177B

COVER

SERIAL: 104-419

1шт.

11

2621-3177C

COVER

SERIAL: 420

1шт.

12

2621-3178

COVER

SERIAL: 1-103

1шт.

12

2621-3178A

COVER

SERIAL: 104-120

1шт.

12

2621-3178B

COVER

SERIAL: 121

1шт.

13

2621-3179

COVER

SERIAL: 1-120

1шт.

13

2621-3179A

COVER

SERIAL: 121

1шт.

18

S0515253

BOLT M12X1.75X30

desc: BOULON A 6 PANS

10шт.

19

S5010713

WASHER;PLAIN M12

desc: RONDELLE PLATE

10шт.

20

S0511853

BOLT M10X1.5X20

desc: BOULON A 6 PANS

26шт.

21

2114-1058D10

WASHER;PLAIN

desc: RONDELLE PLATE

22шт.

23

S5010613

WASHER;PLAIN M10

SERIAL: 4

4шт.
