Запчасти Doosan Daewoo PILOT PIPING(5-1) BODY PARTS

-

2400-1693

PIPING;PILOT

SERIAL: 368

-2шт.

2

2420-9417

VALVE;REMOCON

SERIAL: 219-385

1шт.

2

2420-9544

VALVE;REMOCON

SERIAL: 386

1шт.

3

S0505053

BOLT M6X1.0X25

desc: BOULON A 6 PANS

4шт.

14

2621-2752

PLATE PL 1.2

desc: PLAQUE CAOUTCHOUC

1шт.

20

S5102302

WASHER;SPRING M6

desc: RONDELLE ELASTIQUE

4шт.

32

S8000111

O-RING P11

REP_PNO: 8202-009

19шт.

33

2181-1126D14

ADAPTER PF(0)1/4XPF1/4

desc: RACCORD

14шт.

36

2181-1951D1

TEE PF1/4(0)XPF1/4XPF1/4

desc: TE

2шт.

44

2471-1133

ADAPTER;FILTER PF(0)1/4XPF1/4

desc: RACCORD

1шт.

47

2181-1702D4

ELBOW PF(0)1/4XPF1/4

desc: COUDE

1шт.

59

2184-1046D42

HOSE PF1/4-720L

desc: TUYAU FLEXIBLE

2шт.

77

2184-1046D32

HOSE PF1/4-480L

desc: TUYAU FLEXIBLE

1шт.

80

2184-1249D1

HOSE PF1/4-1500L

desc: TUYAU FLEXIBLE

2шт.

95

2184-1249D21

HOSE PF1/4-3200L

desc: TUYAU FLEXIBLE

2шт.

96

2184-1249D3

HOSE PF1/4-3600L

desc: TUYAU FLEXIBLE

1шт.

98

2184-1249D6

HOSE PF1/4-3300L

desc: TUYAU FLEXIBLE

1шт.

111

2181-2281D1

TEE PF1/4XPF(0)1/4XPF1/4

desc: TE

1шт.

115

2184-1045D55

HOSE PF1/4-990L

desc: TUYAU FLEXIBLE

1шт.

116

2184-1045D143

HOSE PF1/4-700L

desc: TUYAU FLEXIBLE

1шт.
