Запчасти Doosan Daewoo MAIN PIPING-GRAPPLE FRONT PARTS

-

2400-2094

MAIN PIPING;GRAPPLE

SC: D

-2шт.

1

2140-1620A

PIPE

desc: TUYAU

2шт.

2

2184-1100D249

HOSE PF1-1250L

desc: TUYAU FLEXIBLE

1шт.

3

2184-1100D177

HOSE PF1-1320L

desc: TUYAU FLEXIBLE

1шт.

4

2184-1250D48

HOSE;PROTECTOR-3000L

desc: TUYAU FLEXIBLE

2шт.

5

2181-1126D20

ADAPTER

desc: RACCORD ADAPTATEUR

2шт.

6

S8000141

O-RING

desc: JOINT TORIQUE

2шт.

7

S2212366

BOLT;SOCKET M10X1.5X35

desc: BOULON A 6 PANS

24шт.

8

2180-1026D19

O-RING

desc: JOINT TORIQUE

6шт.

9

2181-9078

FLANGE

desc: FLASQUE EN DEUX PARTIES

8шт.

10

2197-2545A

BRACKET

desc: SUPPORT

1шт.

11

S5102703

WASHER;SPRING M12

desc: RONDELLE ELASTIQUE

4шт.

12

S0560453

BOLT M12X1.75X35

desc: BOULON A 6 PANS

2шт.

13

2114-1058D30

WASHER;PLAIN

desc: RONDELLE PLATE

2шт.

14

S0561053

BOLT M12X1.75X65

desc: BOULON A 6 PANS

2шт.

15

2124-1026D3

CLAMP;PIPE

desc: ATTACHE DE TUBE

2шт.
