Запчасти Doosan Daewoo COOLING WATER PUMP ENGINE PARTS

1

65.06500-6145C

WATER PUMP ASSY

desc: POMPE

1шт.

2

65.06501-0076C

HOUSING;WATER PUMP

SC: D

1шт.

3

65.06520-6007

SEAL;MECHANICAL

desc: . JOINT

1шт.

4

65.06506-0023

IMPELLER

desc: . TURBINE

1шт.

5

65.93410-0027

BEARING;WATER PUMP

desc: . PALIER

1шт.

6

06.29020-0132

RING;SNAP

desc: . BAGUE

1шт.

7

65.06504-0030A

HUB

desc: . MOYEU

1шт.

8

65.06901A0019

GASKET;WATER PUMP INNER

desc: . JOINT

1шт.

9

65.06512-0010

COVER;WATER PUMP

desc: . COUVERCLE

1шт.

10

06.04201-8907

BOLT;SLOTTED HEAD M6X14

desc: . BOULON A 6 PANS

3шт.

11

65.06901A0020

GASKET;WATER PUMP

desc: JOINT

1шт.

12

06.01913-3121

BOLT ASS'Y M8X50

desc: BOULON A 6 PANS

3шт.

13

06.01913-3125

BOLT ASS'Y M8X70

desc: BOULON A 6 PANS

1шт.

14

06.01913-3126

BOLT ASS'Y M8X75

SERIAL: 031211

1шт.

14

06.01013-9121

BOLT ASS'Y M8X80

SERIAL: 031212

1шт.

15

06.01914-3225

BOLT ASS'Y M10X70

desc: BOULON A 6 PANS

1шт.

16

65.06611-0123A

FLANGE;FAN

desc: BRIDE

1шт.

17

65.06606-0055

PULLEY;FAN

desc: POULIE

1шт.

18

65.06601-5064

FAN;COOLING

desc: VENTILATEUR

1шт.

19

06.01013-9128

BOLT;HEX. M8X130

desc: BOULON A 6 PANS

6шт.

20

06.16731-2107

WASHER;SPRING

desc: RONDELLE ELASTIQUE

6шт.
